1 Reading Before Proceeding

1.1 Safety Precautions

Please read the safety precautions carefully to ensure the correct use of your mobile phone.

Do not crash, throw, or puncture your mobile phone. Avoid dropping, squeezing, or bending your mobile phone.

Do not use your mobile phone in a moist environment, such as the bathroom. Prevent your mobile phone from being soaked or washed in liquid.

Do not switch on your mobile phone when it is prohibited to use phones or when the phone may cause interference or danger.

Do not use your mobile phone while driving.

Follow any rules or regulations in hospitals and health care facilities. Switch off your mobile phone near medical apparatus.

Switch off your mobile phone in aircraft. The phone may cause interference to control equipment of the aircraft.

Switch off your mobile phone near high-precision electronic devices. The phone may affect the performance of these devices.

Do not attempt to disassemble your mobile phone or its accessories. Only qualified personnel are allowed to service or repair the phone.

Do not place your mobile phone or its accessories in containers with a strong electromagnetic field.

Do not place magnetic storage media near your mobile phone. Radiation from the phone may erase the information stored on them.

Do not put your mobile phone in a high-temperature place or use it in a place with flammable gas such as a gas station.

Keep your mobile phone and its accessories away from children. Do not allow children to use your mobile phone without guidance.

Use only approved batteries and chargers to avoid the risk of explosions.

Observe any laws or regulations on the use of wireless devices. Respect others??? privacy and legal rights when using your wireless device.

Strictly follow the relevant instructions of this manual while using the USB cable. Otherwise your mobile phone or PC may be damaged.

1.2 Personal Information and Data

Security

The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information.

???Place your device in a safe area toprevent itfrom unauthorized use.

???Setyour device screen to lockandcreate a password orunlock pattern to openit.

???Periodically backup personal information kept on your memorycard or stored in your device memory. If you change to a different device, be sure to move ordelete any personal information on yourold device.

???If you are worried about viruseswhen you receive messagesor emails from a stranger,youcandelete them without opening them.

???If you use yourdevice to browse the Internet, avoid websites thatmightpose a security riskto avoid theftofyour personal information.

???If you use services such as Wi-Fi tether or Bluetooth,set passwordsfor these services to prevent unauthorized access. When these services are not in use,turn them off.

???Install orupgradedevice security software and regularlyscan for viruses.

???Be sure to obtainthird-party applicationsfrom a legitimate source.Downloaded third-partyapplicationsshould be scanned for viruses.

???Install security softwareor patchesreleased byHuawei or third-partyapplication providers.

???Some applications require andtransmit location information. Asa result, a third- party maybe able toshare yourlocationinformation.

???Yourdevice may provide detection and diagnostic information to third-party application providers.Third partyvendors use this information to improvetheir products and services.

???If you have concerns aboutthe security ofyour personal information and data, please contactmobile@huawei.com.

1.3 Legal Notice

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd. and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders.

Trademarks and Permissions

, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.

Android is a trademark of Google Inc.

Other trademarks, product, service and company names mentioned are the property of their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and therefore may not be activated or may be limited by local network operators or network service providers. Thusthedescriptionshereinmaynotmatchexactlytheproductoritsaccessoriesyou purchase.

HuaweiTechnologiesCo.,Ltd.reservestherighttochangeormodifyanyinformation or specifications contained in this manual without prior notice and without any liability.

Third-Party Software Statement

HuaweiTechnologiesCo.,Ltd.doesnotowntheintellectualpropertyofthethird-party software and applications that are delivered with this product. Therefore, Huawei Technologies Co., Ltd. will not provide any warranty of any kind for these third-party softwareandapplications.NeitherwillHuaweiTechnologiesCo.,Ltd.providesupport to customers who use these third-party software and applications, nor be responsible or liable for the functions of these third-party software and applications.

Third-party software and applications services may be interrupted or terminated at any time. Huawei Technologies Co., Ltd. does not guarantee that any content or service would be maintained for any period during its availability. Third-party service providers provide contentand services through network or transmission tools outside of the control of Huawei Technologies Co., Ltd. To the greatest extent permitted by applicable law, it is explicitly stated that Huawei Technologies Co., Ltd. shall not compensate or be liable for services provided by third-party service providers, or the interruption or termination of third-party contents or services.

Huawei Technologies Co., Ltd. shall not be responsible for the legality , quality, or any other aspects of any software installed on this product, or for any uploaded or downloaded third-partyworks,suchastexts,images,videos,orsoftware.Customers shall bear the risk for any and all effects, including incompatibility between the software and this product, which result from installing software or uploading or downloading the third-party works.

This product uses the open-source Android??? platform. Huawei Technologies Co., Ltd. has made necessary changes to the platform. Therefore, this product may not support all the functions that are supported by the standard Android platform or may be incompatible with third-party software. Huawei Technologies Co., Ltd. shall not be liable for any of such situation.

DISCLAIMER OF WARRANTIES

THE CONTENTS OF THIS MANUAL ARE PROVIDED ???AS IS???. EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

LIMITATIONS OF LIABILITY

TOTHEMAXIMUMEXTENTPERMITTEDBYAPPLICABLELAW,IN NOEVENT

SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST

PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED

SAVINGS.

THE MAXIMUM LIABILITY (THISLIMITATION SHALL NOT APPLY TO LIABILITY

FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS

SUCHALIMITATION)OFHUAWEITECHNOLOGIESCO.,LTD.ARISINGFROM

THE USE OF THE PRODUCT DESCRIBED IN THIS DOCUMENT SHALL BE

LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF

THIS PRODUCT.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and be responsible to obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.

2 Getting to Know Your Mobile Phone

2.1 Mobile Phone View

2.1.1 Phone at a Glance

All the pictures in this guide are for your reference only. The actual appearance and display features depend on the mobile phone you purchase.

??? Press and hold to power on your mobile phone.

??? Press and hold to open the Phone options menu.

???Press to lock the screen when your mobile phone is active.

???Touch to return to the previous screen.

??? Touch to exit any application you are running.

??? Touch to hide the keyboard.

Touch to open the menu on an active screen.

??? Touch to return to the Home screen.

??? Touch and hold to show the most recently used applications.

??? TouchtoopenGooglesearchforsearchingyourmobilephoneandthe web.

??? Touch and hold to open Google search by voice.

2.2 Installing Your Mobile Phone

2.2.1 Installing the Battery and the microSD Card

1 Remove the battery cover 2 Install the battery

2.2.2 Charging the Battery

Before charging the battery, ensure that it has been properly inserted into your phone.

1.Connect the USB cable that came with your mobile phone to the charger.

2.Connect the USB cable to your mobile phone. Then, plug in the connector of the charger to an electrical outlet. The phone begins charging.

If your mobile phone is charged when it is powered on, the battery icon on the

Notification bar shows the charging status. When the battery icon changes to , it indicates that your mobile phone is fully charged.

2.2.3 Important Information About the Battery

???If the battery has not been used for a long period of time, you may not be able to power on your mobile phone immediately after you begin charging the battery. Allow the battery to charge for a few minutes with the phone powered off before attempting to power on the phone.

???The battery will not hold a charge for the way it did when it was new. When the battery life becomes noticeably shorter than usual after being charged properly, replace the battery with a new one of the same type.

???Using data services increases demand on the battery and will reduce the length of time it can hold a charge.

???The time required to charge the battery depends on the ambient temperature and the age of the battery.

???When the battery is low on power, the phone plays an alert and displays a prompt. When battery power is almost exhausted, your phone will power off automatically.

2.2.4 Battery Saving Tips

The longevity of battery power depends on the network that you connect to, and how you use your mobile phone.

Try the following to conserve battery power:

???Use normal wallpaper rather than live wallpaper.

???When your mobile phone is not in use, switch off the screen.

???Resetthetimeittakesforyourscreenlighttoswitchoffwhenyouleave yourphone idle.

???Lower the screen brightness.

???Use the AC adapter to plug your phone into an external power source whenever possible.

???Turn Bluetooth off when you are not using it.Only make your phone visible to other Bluetooth devices when you need to establish a Bluetooth connection.

???Switch off Wi-Fi when you are not using it.

???Turn off your phone connection to GPS satellites when you are not using it.

???Lower the volume.

???Close power-draining programs, when you do not need them.

???Turn off the data service.

2.3 Power On or Off Your Mobile Phone

2.3.1 Powering On Your Mobile Phone

Press and hold . The first time you power on your phone, you will be asked to sign in to your account and set up your mobile phone.

2.3.2 Setting Up Your Mobile Phone

The first time you power on your mobile phone, the phone displays a setup wizard to help you set up the phone.

The setup wizard helps you:

???Learn aboutyour mobile phone

???Create or sign into your account

???Make some initial decisions abouthowyou want to use your mobile phone

2.3.3 Powering Off Your Mobile Phone

1.Press and hold to open the Phoneoptionsmenu.

2.Touch Power off.

3.Touch OK.

2.4 Using the Touchscreen

2.4.1 Touchscreen Actions

???Touch:Usethetouchofyourfingertoselectanitem,confirmaselection,orstartan application.

???Touchandhold:Touch anitem with your fingerand continue to press down until yourmobilephoneresponds.Forexample,toopentheoptionsmenu fortheactive screen,touch the screen and hold down until the menu appears.

???Flick: Move yourfinger either vertically orhorizontallyacross the screen.

???Drag: Touch and hold the desired itemwith your finger. To movean item, drag the item toanypartofthe screen.You can drag an icon to move or delete it.

2.4.2 Rotating Your Mobile Phone Screen

The orientation of most screens will rotate with the phone as you turn it from upright to sideways and back again.

Touch > Settings > Display> Auto-rotate screen to disable the function.

2.5 Locking and Unlocking the Screen

2.5.1 Locking the Screen

??? When your phone is on, press to lock the screen. When the screen is locked, you can still receive messages and calls.

??? If your phone is idle for a while, the screen will lock automatically.

2.5.2 Unlocking the Screen

1.Press to wake up the screen.

2.Drag the lock icon from left to right to unlock the screen.

If you have set up a screen unlock pattern, you will be prompted to draw the pattern on the screen to unlock it.

2.6 Home Screen

Display area:

Shows the operation and display areas of your phone.

Indicates the current screen.

Touch to view thumbnails of all screens.

Shortcuts

Touch to view all your applications.

Touch and hold one of the shortcuts until the mobile phone vibrates, you can dragittoyourdesiredlocationormoveittothetrash.Youcanalsodragascreen item to the shortcut position.

2.6.1 Notification and Status Icons

2.6.2 Notifications Panel

Your mobile phone will notify you when you receive a new message or there is an upcoming event. The notifications panel also informs you of alarms and settings. Open the notifications panel to see your network operator or to view a message, reminder, or event notification.

Opening the Notifications Panel

1.When a new notification icon appears on the notification bar, flick down to open the notifications panel.

Touch > Notifications to open the panel.

2.On the panel, you can:

???Touch a notification to open the related application.

???Touch Clear to clear all notifications.

Closing the Notification Panel

Flick up to close the panel.

2.6.3 Viewing Other Parts of the Home Screen

Flick your finger left or right across the Home screen.

Touch to view thumbnails of the Home screen and its extensions. Touch a thumbnail to open the screen.

Touch > Home settings > Advanced settings > Screen number to set the screen number.

2.6.4 Customizing the Home Screen

Adding a New Screen Item

1.Touch and hold a blank area on the Home screen until the Selectactionmenu is displayed.

You can also touch > Add to display the Select action menu.

2. Select an item to add it to the Home screen.

Moving a Screen Item

1.Touch and hold an item on the Home screen until the item expands in size and the mobile phone vibrates.

2.Without lifting your finger, drag the item to the desired position on the screen, and then release it.

Removing a Screen Item

1.Touchand hold an item ontheHome screen untiltheitemexpands and themobile phone vibrates.

2.Without lifting your finger, drag the item to the trash can. When the item and the trash can turn red, the item is ready to be removed.

3.Release the item to remove it from the Home screen.

2.6.5 Service Shortcuts

1.Open the notification bar.

2.Touch at the top of the screen to switch on or off data services.

You can also touch , , or to switch on or off corresponding services.

1.On the Home screen, touch > Wallpaper.

2.Touch option to select a picture and set it as the wallpaper.

2.6.8 Changing the Theme

1.On the Home screen, touch > Homesettings.

2.Do any of the following:

???Touch Theme to select a theme.

???Touch Application icons to select a series of application icons.

???Touch Download to download themes from the Internet.

3.Touch Save.

2.6.9 Editing a Screen Item

1.Touch and hold an item on the Home screen until the Select actionmenu is displayed.

2.Touch Edit icon, and then do any of the following:

???Customize the title of the screen item.

???Select a new icon for the screen item.

3.Touch Save.

2.7 Application List

Application list holds icons for all of the applications on your phone. You can touch on the Home screen to open the application list.

2.7.1 Moving Icons in the Application List

1.In the application list, touch .

2.Touch and hold the icon you want to move in the application list until the icons shake.

3.Without lifting your finger, drag the icon to the desired location, and then release it.

To move more icons, repeat step 2 and 3. 4. Touch or touch to save.

2.8 Using a microSD Card

2.8.1 Using the microSD Card as USB Mass Storage

To transfer all your favorite music and pictures from your PC to your mobile phone???s microSD card, set the microSD card as USB mass storage.

1.Connect yourmobile phonetoyour PCwiththeUSBcable. YourPCwill detect the microSD card as a removable disk.

2.Open the notification bar, and then touch USBconnected.

3.Touch TurnonUSBstoragein the dialog box thatopens to confirm that you want to transfer files.

You can now transfer files from your PC to your mobile phone???s microSD card.

When yourmicroSDcardactsasUSB massstorage, yourmobilephonewillnot use this memory space. Your PC will tell you how to safely disconnect the USB mass storage device (your mobile phone) when you have finished transferring files.

2.8.2 Removing the microSD Card

1.Touch > Settings.

2.Scroll down the screen, and then touch Storage> Unmount SDcard.

3.Carefully remove the microSD card.

3 Calling

To make a phone call, you can dial a number or touch a number from your contact list, on a Web page, or in a document. When you are on a call, you can answer other incoming calls or send them to your voicemail box. You can also set up conference calls with several participants.

3.1 Making a Call

Tomakeacall,youcanusetheDialerapplication,orselectanumberfrom Contacts or Call log.

When you are on a call, you can touch to use other functions. To return to the calling screen, flick the notification bar down and touch Current call.

Do not block the microphone at the bottom of your phone if you want your voice heard.

3.1.1 Making a Call with the Dialer Application

If you are already working with Contacts or Call log, touch the Dialer tab. 2. Touch the appropriate numeric keys to enter the phone number.

Your mobile phone supports the SmartDial function, that is, when you touch

numbers on the dialer, the phone automatically searches among your contacts and lists the matching results based on the accuracy. If no contact is matched with your entered information, the phone will not display any result.

3. Touch to initiate the call.

During a call, touch Dialpad to enter other numbers on the dialpad.

3.1.2 Making a Call from Contacts

1. Touch > Contactsto display the contact list.

If you are already working with Dialer or Call log, touch the Contacts tab.

2.In the list, touch the contact you want to call.

3.Touch to dial the phone number.

3.1.3 Making a Call from Call log

1.If you are already working with Contactsor Dialer, touch the Calllogtab.

2.Touch to the right of the log entry to dial.

If you touch and hold a log entry, the options menu will open.

3.2 Answering or Rejecting a Call

3.2.1 Answering an Incoming Call

Whenyoureceive aphone call,the incoming call screenopenswiththecaller'sname and number that you have entered in Contacts.

Drag the to the right to answer the call.

3.2.2 Ending a Call

During a call, touch End to hang up.

3.2.3 Rejecting an Incoming Call

Drag the to the left to reject the call.

3.3 Other Operations During a Call

3.3.1 Making a Conference Call

If you receive a new call while you are already on a call, you can connect the second call to the call you are on. This feature is known as conference calling. You can also set up a conference call with multiple callers.

Contact your network operator to learn if conference calls are supported and, if yes, how many can participate.

1.To initiate a conference call, dial the number of the first participant. After you have connected to the first participant, keep the connection open, touch Addcall.

2.Enter the phone number of the next person you want to join the conversation and

touch ,orselectsomeonefromyourCalllogorContacts.Thefirstparticipant is automatically placed on hold while you do this.

3.Once you have connected to the second person, touch > Mergecallsto begin the conference call.

4.To end the conference call and disconnect everyone, touch End.

3.3.2 Switching Between Calls

If you receive a new call while you are already on a call, you can switch between the two calls.

1.While you are on the first call and the second call comes in, answer the incoming call, and then touch > Managecalls.

2.The current call is placed on hold and you are connected to the first call.

3.4 Using Call log

The Calllogcontains a list ofcallsthat you have dialed, received, ormissed.You can use the call log to reference a recently called number quickly or add an incoming number to your contact list.

3.4.1 Adding an entry to Contacts

1.If you are already working with Dialeror Contacts, touch the Calllogtab.

2.Touch and hold the entry you want to add.

3.Touch Addtocontacts in the options menu.

4.Touch Createnewcontact or scroll through the contact list and touch an existing contact name.

3.5 Using Airplane Mode

Somelocationsmayrequireyoutoturnoffyourphone???swirelessconnections.Rather than powering off your phone, you can place it in Airplane mode.

1.Press and hold .

2.Touch Airplanemode in the options menu.

3.6 TTY Operation

3.6.1 Using the TTY Device

The Teletypewriter (TTY) isa typewriting device. By connecting the phone to the TTY device,you can use the TTY functions to send/receive messages. When you use the TTY function, do as follows:

1.Connect the TTY device to the headset jack of the phone and set the phone to the TTY mode.

2.Make or answer calls as normal.

3.When the call is put through, use the TTY device to send or receive the letters.

4.Press the Endto end the call.

3.6.2 Setting the TTY Mode

1.Touch > Settings> Call settings> TTY mode.

2.Select one TTY mode.

???TTY Off: The standard voice speaking mode and the listening mode.

???TTY Full: Transmit and receive the TTY characters.

???TTY HCO: Transmit TTY characters but receive by listening to the earpiece.

???TTY VCO: Receive TTY characters but transmit by speaking into the microphone.

3.7 Setting Hearing Aid Compatibility

Touch > Settings > Call settings > Hearing aids to set your phone to be

compatible with a hearing aid.

4 Contacts

The Contacts application enables you to save and manage information such as phone numbers and addresses of your contacts. After you save contact information on your mobile phone, you have easy access to the people with whom you want to communicate.

4.1 Opening the Contacts Application

If you have a new mobile phone and have not yet added any contacts, Contacts displays a message with hints on how to start adding contacts to your mobile phone.

Touch > Contacts to open the Contacts application.

All of your contacts are displayed alphabetically in a list that you can scroll through.

4.2 Adding a Contact

1.In the contact list, touch > Createcontact.

2.If you have more than one account with contacts, touch the account to which you want to add the contact.

3.Enter the contact's name, and then add detailed information such as phone number or address.

4.When you are finished, touch Doneto save the contact information.

4.2.1 Adding a Contact to Your Favorites

???Touch and hold the contact you want to add to Favorites. Then touch Add to Favorites.

???Touch acontact, and thentouch thestar to the rightofthe contact???sname.The star turns gold.

4.3 Indexing Contacts

You can index your Contacts to quickly find your desired contact.

1.Touch > Contacts.

2.Touch or move any letter in the alphabet to list all contacts starting with the letter.

4.4 Searching for a Contact

1. In the contact list, touch > Search.

2. Enter the name of the contact you wish to search for. As you type, contacts with matching names appear below the search box.

4.5 Editing a Contact

You can make changes to the information you have stored for a contact at any time.

1.In the contacts list, touch and hold the contact whose details you want to edit, and then touch Editcontact in the options menu.

2.Touch the category of contact information you wish to change: name, phone number, email address, or any other information you recorded earlier.

3.Make the desired changes to the contact information, and then touch Done. To cancel all of your changes, touch Cancel.

4.6 Communicating with Your Contacts

From the Contacts or Favorites tab, you can quickly call or send a text (SMS) or multimedia message(MMS)toacontact???sdefaultphonenumber.Youcan alsoopen details to view a list of all the ways you can communicate with that contact. This section describes how to communicate with a contact when you view your contacts list.

4.6.1 Connecting Through Quick Contact for Android

1.Touch the contact's picture or picture frame (if you have not assigned a picture to the contact) to open Quick Contact for Android.

2.Touch the icon for the way you want to communicate with the contact.

The icons available depend on the information you have entered for the contact, the applications on your phone, and the accounts you have.

4.6.2 Communicating with a Contact

1.In the contacts list, touch the contact that you want to communicate with.

2.On the contact???s details screen, touch the icon to the right of the number to call or send messages.

4.7 Deleting a Contact

1. In the contacts list, touch and hold the contact that you want to delete, and then touch Deletecontact in the options menu.

2. Touch OKto confirm that you want to delete the contact.

4.8 Managing Groups

You can create your own groups or use default groups, such as Coworkers, Family and Friends.

4.8.1 Creating a Group

2.In the groups list, touch , and then touch Creategroup.

3.Enterthenameandpictureyouwanttostoreforthegroup,andthengivethegroup a ringtone.

4.Touch AddMembersto add members on the group list.

5.Select the contacts to be added to the group, and then touch OK

6.When you are finished, touch Doneto save the group information.

4.8.2 Editing a Group

You can always make changes to the information you have stored for a group.

1.Inthegroupslist,touchandhold thegroupwhosedetailsyouwanttoedit,andthen touch Edit groupin the options menu.

2.Make the desired changes to the group information, and then touch Done. To cancel all changes you made to the group information, touch Cancel.

4.8.3 Adding a Contact to Your Groups

To add a contact to your groups, you can do any of the following:

???Touch and hold the contact you want to add to Groups. Then touch Add to groups.

???When editing a group, press , and then touch Add Members to select the contacts you want to add to group.

4.9 Joining and Separating Contacts

You may have duplicate contacts if you import contacts by:

???Addingan account, such asa Gmail account.

???Using thesocial networking services such as Facebookor Twitter. (Ifyour phone has the Streamsfunction, you can use it to accessFacebook or Twitter.)

???Using other methods,such as byexchangingemails.

To avoid duplication, join two or more contacts together to form a single contact.

4.9.1 Joining Contacts

Make sure you have added an accountand have duplicate contacts in Contacts.

1.Touch > Contacts.

2.Touch a duplicated contact.

3.Touch JoinedContacts> Addcontact.

4.Select the contact to be joined to combine two duplicate contacts.

Two contacts will be joined together and displayed as one contact. Touch the contact to view the joined information. If you touch the contact, and then touch N Joined Contacts, you can see that the contact is joined together by two contacts.

4.9.2 Separating Contacts

If contact information from different sources was joined together with error, you can separate the contacts.

1.Touch > Contacts.

2.Touch a contact to be separated.

3.Touch NJoinedContacts.

4.Select a contact, and then it is separated.

The contact is then separated into two contacts and displayed as two contacts in

Contacts.

4.10 Staying Close to Your Friends

The first time you do this, you will be requested to sign in to your account.

5 Using the Onscreen Keyboard

5.1 Displaying the Keyboard Panel

To enter text, use the onscreen keyboard. Some applications open the keyboard automatically. In others, touch a text field to open the keyboard.

Touch the space where you want to write text to display the keyboard. Touch to hide the keyboard.

Touch and hold the space where you usually write your text to open the options menu.

5.1.1 Choosing an Input Method

1.Touch and hold the space where you enter your text until the Edit text menu is displayed.

2.Touch Input method.

3.Select the input method.

The keyboard panel will be displayed automatically.

5.1.2 Using the Android Keyboard

q w e r t y u i o p a s d f g h j k l

z x c v b n m

Touch to insert a space.

Touch to enter text by voice.

Touch to delete a character to the left of the cursor. Touch and hold to delete all characters to the left of the cursor.

Touch to select input method or set input method.

Touch to change from text mode to symbol/number mode.

Touch once to capitalize the next letter you type.

Touch and hold for all caps.

Touch > Settings > Language & keyboard > Android keyboard >

Voice input to turn on or turn off voice input.

5.1.3 Using the Swype Keyboard

Touch to change from text mode to symbol/number mode.

Touch and hold to get helpful tips.

Touch to get swype functions.

Touch once to capitalize the next letter you type.

Touch twice for all caps.

5.1.4 Using the Landscape Keyboard

If you find the keyboard inconvenient or difficult to use, turn your mobile phone sideways. The screen will display the keyboard in landscape orientation, providing you with a wider keyboard layout.

5.2 Customizing Keyboard Settings

1.Touch > Settings> Language&keyboard.

2.Select an input method to customize the keyboard settings.

6 Messaging

The Messaging application allows you to exchange text messages (SMS) and multimedia messages (MMS) with anyone using an SMS-or-MMS-capable phone. With the Email application you can read and send emails.

6.1 SMS and MMS

6.1.1 Opening Messaging

Touch > Messaging.

6.1.2 Creating and Sending a Text Message

1.Touch > Messaging > Newmessage.

2.Enter a phone number or a contact's name in the Tofield, or touch to select a contact from Contacts.

As you enter the phone number or the contact's name, the phone displays possible matches from your contacts. Select a contact from the list of possible matches or continue entering.

Afteryouselectacontactorfinishenteringanumber,addacommaandyoucan enter another recipient. You can also touch a previously entered contact again to edit or delete it.

3. Touch the composition text box to start entering your message.

While entering your message, you can touch > Insert contact to insert contact information.

4. When you are ready to send the message, touch Send.

The message list opens, and your name appears in the list, followed by the message you just sent. Responses appear in the window. As you view and send additional messages, a message thread is created.

6.1.3 Creating and Sending a Multimedia Message

You can use multimedia messages to make everyday communications very special. You can record a message and send it as an audio file, sing 'Happy Birthday' and send it to friend, or send a slideshow of photographs of a special event. The possibilities are endless.

1.Touch > Messaging > Newmessage.

2.Enter a phone number in the To field, or touch to select a contact from

Contacts.

3.Touch the composition text box to start entering your message.

If you want to enter a smiley face, touch , and then touch Insert smiley. 4. Touch to display the options panel.

???Touch Add subject to add the message subject. Your mobile phone is now in multimedia message mode.

???Touch Attach to add a picture, music, or video file.

5.When the message is ready to be sent, touch Send.

You can select a media file directly (music, video or picture) and send it as an attachment to a multimedia message. In FileManager, touch and hold a media file, and then touch Share > Messaging.

Adding a Slideshow

If you want to attach more than one file to your message, use the Slideshow option.

1.On the message editing screen, touch to display the options panel.

2.Touch Attach> Slideshow, and then select a slide to start editing it.

3.Touch and touch Addslideto add more slides.

4.Touch Doneto finish composing your message and return to the multimedia message screen.

5.To alter your multimedia message, touch the slideshow on the multimedia message screen. When the message is ready to be sent, touch Send.

6.1.4 Opening and Viewing a Multimedia Message

1. In the message list, touch the message thread you wish to view. 2. Touch the multimedia message to view the message.

6.1.5 Replying to a Message

1.In the message list, touch a text or multimedia message thread to open it.

2.Touch the text box to compose your message, and then touch Send.

You can also do the following to reply to a message: In Messaging, touch > Multiselect. Select one or more message threads, and then touch Reply.

6.1.6 Copying a Text Message to Calendar

1.In the message list, touch a text message thread to open it.

2.Touch and hold one of the messages, and then touch Copymessageto.

3.Touch Calendarto save it as a note or an event.

For information about how to use Calendar, refer to the relevant sections.

6.1.7 Customizing the Message Settings

In the message list, touch , and then touch Settings to customize the message settings.

6.2 Email

Your mobile phone also puts email at your fingertips. With your phone???s Email application,you can useyour email accountwith Yahoo!,AOL,orotherpopularemail services on your phone.

6.2.1 Adding an Email Account

When using the Email application for the first time, you must configure an email account.The Email setupwizard helps you setup your account. Anumber ofpopular email systems are supported. Youcanworkwith thesameemail service thatyou use on your PC or you can select another email service.

1.Touch > Email.

2.To customize your email settings, answer the onscreen prompts, and then touch Next. Or touch Manual setupif you want to set the mail server yourself.

If you choose to set up your account manually, you will need the correct parameters for the account. Contact your email service provider for this information.

3.Enter the account name and the name you want other people to see when they receive an email from you.

4.Touch Done.

After the initial setup, your Email opens to the screen you were viewing the last time the application was opened. If, however, the Email application has not been used for a period of time, it displays the contents of your Inbox or the accounts screen (if you have more than one account).

Adding Other Email Accounts

1.After creating your initial email account, touch on the Inboxscreen, and then touch Accountsto access the accounts screen.

2.Touch on the accounts screen, and then touch Addaccountto create another email account.

When adding an additional email account, you have the option to use the new account to send all outgoing messages.

6.2.2 Viewing an Email Message

1.On the accounts screen, touch the email account you want to use.

2.Access a folder, and then touch the message that you want to view.

6.2.3 Creating and Sending an Email Message

1.On the accounts screen, touch the email account you want to use.

2.On the Inboxscreen, touch , and then touch Composein the options panel.

3.In the Tofield, enter the name or the email address.

4.Enter the subject of your message and compose the message.

To send an attachment with the message, touch , and then touch Add attachment.

5. When you are finished, touch Send.

If you are not ready to send the message, touch Save as draft or touch to save the message as a draft.

6.2.4 Replying to an Email Message

1. On the accounts screen, touch the email account you want to use. 2. Touch the email message you want to reply to.

3. Touch Replyor Replyall to reply to the email message.

6.2.5 Saving an Email Attachment

1. On the Accounts screen, touch the email account you want to use. 2. Touch the email message you want to view.

3. Touch Saveto download the email attachment.

6.2.6 Deleting an Email Account

1. On the accounts screen, touch and hold the email account you want to delete. 2. Touch Removeaccount.

3. Touch OK.

6.2.7 Changing Email Account Settings

You can change a number of settings for an account, including how often you check for emails, how you are notified of a new mail, and details about the servers the account uses to send and receive mails.

Your account???s incoming and outgoing settings depend on the kind of email

service you are using. You can enter the necessary details manually, although you may need to contact your email service provider to obtain the correct information for the account.

1.Touch > Email.

2.On the accounts screen, touch and hold the email account you want to change.

3.Touch Accountsettings.

4.Change General settings, Signaturesettings, Notificationsettings, or Server settings.

7 Getting Connected

7.1 Turning on the Data Service

1. Touch > Settings.

2. Touch Wireless&networks > Mobilenetworks.

3. Select the Dataenabledcheck box to turn on the data connection.

7.2 Wi-Fi

Wi-Fi gives you wireless access to broadband Internet access. To use Wi-Fi on your mobile phone, you need to have an access to wireless access points (hotspots). Obstacles that block the Wi-Fi signal will reduce its strength.

2.Touch Wireless&networks> Wi-Fisettings. You willseea listofdetectedWi-Fi networks in the Wi-Fi networks section.

3.Touch a Wi-Fi network to connect to it.

???If you select an open network, you will be automatically connected to the network.

???If you select a network that is secured with Wired Equivalent Privacy (WEP) andconnecttoitforthefirsttime,enterthepassword,andthentouch Connect. If you connect to a secured wireless network that you have already used, you will not be prompted to enter the password again unless you reset your mobile phone to its default settings.

On the Wi-Fi settings screen, touch Add Wi-Fi network to add a new Wi-Fi network.

7.3 Sharing Your Phone???s Data

Connection

Youcanshareyourmobilephone'sdataconnectionwithasinglecomputerviaaUSB cable: USB tethering. You can share your mobile phone's data connection with devices at the same time, by turning your phone into a portable Wi-Fi hotspot.

7.3.1 Sharing Your Phone???s Data Connection via USB

To use USB tethering in different operating systems, you may need to prepare your computer to establish a network connection via USB.

You can not share your mobile phone???s data connection and SD card via USB at the same time.

A Tethering Plan from your service provider is required to use this service.

1.Touch > Settings.

2.Touch Wireless & networks > Tethering & portable hotspot.

3.Select the USB tethering check box to share your data connection.

7.3.2 Sharing Your Phone???s Data Connection as a Portable Wi-Fi Hotspot

A Tethering Plan from your service provider is required to use this service.

1.Touch > Settings.

2.Touch Wireless & networks > Tethering & portable hotspot.

3.Select the Portable Wi-Fi hotspot check box to share your data connection.

When Portable Wi-Fi hotspot is selected, you can touch Portable Wi-Fi hotspot settings to change its network name or secure it.

7.4 Browser

Your mobile phone comes with a browser. You can use Browser to access and browse the Internet.

7.4.1 Opening the Browser

Touch > Browser to open the home page.

When the known or open Wi-Fi networks and the mobile networks are present at the same time, your phone will preferably select a Wi-Fi network for internet access.

Open the browser options menu and perform one of the following operations, touch

???Newwindow:Touch toopena newwindow.

???Bookmarks:Touch to displaybookmarks.

???Windows: Touch to go to theweb previewscreen. You can switch toanother web page oropen anewweb page on this screen.

???Refresh: Touch to refresh the currentpage.

???Forward: Touchto browsethenext web page.

???More:Touch to open othermenusandperformoperationssuch assearching, selectingtext, downloading, orsetting options.

7.4.2 Opening a Web Page

3. As you enter the address, matching web page addresses will appear on the screen.Ifyouseetheaddressyou want,touchitandgodirectlytothatwebpageor complete entering the address of the web page you want.

You can store as many bookmarks as you want on your mobile phone.

Adding a Bookmark

1.In a browser screen, go to the web page you want to save as a bookmark.

2.Touch , and then touch Bookmarks> Add. The add bookmark screen opens.

3.Edit the bookmark name as needed and then touch OK.

Opening a Bookmark

1. In a browser window, touch , and then touch Bookmarks.

On the Bookmarks screen, touch the History tab to view the pages you have visited. Or touch the Most visited tab to view the pages you have visited most frequently.

2. Touch the bookmark of the website you want to open.

7.4.5 Customizing the Browser Settings

Customizethebrowsertosuityourbrowsing style.UseBrowserto setpagecontent, privacy, and security preferences. In the browser screen, touch , and then touch

More > Settings.

7.5 Bluetooth

Your mobile phone has Bluetooth, which allows you to create a wireless connection with other Bluetooth devices so you can share files with your friends, talk hands-free with a Bluetooth headset, or even transfer photos on your phone to your PC.

If you are using Bluetooth, remember to stay within 10 meters (33 feet) of other Bluetooth devices. Be aware that obstacles like walls or other electronic equipment may interfere with your Bluetooth connection.

7.5.1 Turning On Bluetooth

1. Touch > Settings.

2. Touch Wireless&networks, and then select the Bluetoothcheck box to turn on Bluetooth. When Bluetooth is turned on, the Bluetooth icon appears in the notification bar.

3. Touch Bluetooth settings, and then select the Discoverableto make your mobile phone visible to other Bluetooth devices.

7.5.2 Pairing and Connecting a Bluetooth Device

Your mobile Bluetooth lets you do the following:

???HandsFreeProfile (HFP): allowsyou to use ahands-free Bluetooth device.

???HeadsetProfile (HSP):allows you to use a mono Bluetooth headset.

???ObjectPush Profile(OPP):allowsyou to transfer files through Bluetooth.

???Advanced Audio Distribution Profile (A2DP):allowsyou tousea stereo Bluetooth headset.

???A/VRemote Control Profile (AVRCP):allowsyou to control what playsthrough the Bluetooth headsetremotely.

Before you useBluetooth,youneed to pair yourmobilephone with anotherBluetooth device as follows:

1.Ensure that the Bluetooth function on your mobile phone is enabled.

2.Touch > Settings> Wireless&networks> Bluetoothsettings. Your mobile phone will then scan for Bluetooth devices in range.

3.Touch the device you want to pair with your mobile phone.

4.Enter the pairing password to complete the connection if necessary.

7.5.3 Sending Files via Bluetooth

With Bluetooth, you can share pictures, videos, or music files with your family and friends. To send files via Bluetooth, do as follows:

1.Touch and hold the file to be sent in your mobile phone or SD card. The active options menu is displayed.

2.Touch Share, and then touch Bluetoothto select a paired device.

7.5.4 Disconnecting or Unpairing a Bluetooth Device

2.Navigate to the Bluetooth devicessection, and then touch and hold the connected device.

You can also just touch a connected device to disconnect it. 3. Touch Unpair to disconnect the device.

8 Entertainment

In addition to being a communication device and personal assistant, your mobile phone also provides you with a multitude of entertainment possibilities. You can take photos, create videos and audio clips, and download and listen to music.

8.1 Taking Photos and Recording Videos

Thecameraisacombinationofcameraandcamcorderthatyoucanusetoshootand share pictures and videos.

8.1.1 Opening Your Camera

???Touch > Camera to open the camera. The camera opens in landscape mode, ready to take a picture or record a video.

???Touch to close the camera.

Capture Screen

Thumbnail of last photo. Touch to 3 preview the photos or videos.

Drag up to record videos, drag down to take photos.

Touch to take a 5 photo.

Touch to customize the camera settings.

On the capture screen, touch to show the capture panel.

8.1.2 Taking a Photo

1.Open your camera and switch to the camera mode.

2.If necessary, change the camera settings. The preview changes as you change the settings.

3.Compose your photo within the photo capture screen.

4.Touch and hold . When the frame turns green, the image is in focus.

5.Release to take your photo.

The photo you just took is displayed for a moment. You can take another photo or preview your photos.

8.1.3 Viewing Your Photos

1.After taking a photo, a thumbnail of the photo you have just taken is shown in the upper right corner of the capture screen. Touch the thumbnail to view it.

2.Touch the onscreen button to do any of the following:

???Touch Share to send the photo in a message or post it online.

???Touch Delete to delete the photo.

???Touch More > Set as to set a picture as contact icon or wallpaper.

8.1.4 Recording a Video

1.Open the camera, and then switch to camcorder mode.

2.If necessary, change the camcorder settings.

3.Frame the scene which you want to start your video.

4.Touch to start recording a video.

5.Touch to stop recording.

8.1.5 Viewing Your Videos

1.Afterrecordinga video,athumbnail ofthe videoyou havejustrecorded isshownin the upper right corner of the Capture screen. Touch the thumbnail to view it.

2.Touch the onscreen button to do any of the following:

???Touch Share to send the video in a message or post it online.

???Touch Delete to delete the video.

On the video playing screen, touch the controls to skip forward or back or to play or pause the video.

8.2 Using the Gallery

Your Gallery application can automatically search for pictures and videos on your mobile phone and microSD card. Use Gallery to sort photos and videos into folders, view and edit pictures, watch videos, and set a picture as wallpaper or as a photo for a contact.

The Galleryapplication categorizes your pictures and videosby storage location and stores these files in folders. Touch a folder to view the pictures or videos inside.

8.2.2 Viewing a Picture

1.In the Gallery, touch the folder that contains the pictures you want to view.

2.Touch the picture to view it in full-screen mode.

3.Touchthe screen.Thenthezoompanelappears.Youcanzoominorzoomouton the picture.

The picture viewer supports the automatic rotation function. When you rotate your mobile phone, the picture adjusts itself to the rotation.

8.2.3 Rotating a Picture

3. Select either RotateLeft or RotateRight. The picture is saved with the new orientation.

8.2.4 Cropping a Picture

1.Whenviewinga picture,touch todisplaythe more operationspanel,andthen touch More> Crop.

2.Use the cropping tool to select the portion of the picture to crop.

???Drag from the inside of the cropping tool to move it.

???Drag an edge of the cropping tool to resize the image.

???Drag a corner of the cropping tool to resize the image without changing the length to width ratio.

3.Touch Saveto save the cropped picture. Touch Discardto discard the changes.

8.3 Enjoying Music

You can download music files to your PC or insert a CD and copy the files to your microSD card so you can listen to music on your mobile phone.

8.3.1 Copying Music to the microSD Card

1.Connect the phone to your computer with a USB cable and mount the microSD card.

2.On the PC, navigate to the USB drive and open it.

3.Create a folder in the root directory of the microSD card (for example, Music).

4.Copy the music from your computer to the folder you have created.

5.After copying music, unmount or eject the drive as required by your PC???s operating system to safely remove the mobile phone.

6.Disconnect the mobile phone from the PC.

The Musicapplication organizes your music files by storage location. It contains four tabs: Artists, Albums, Songs and Playlists.

8.3.3 Playing Music

1.Touch a category on the music library screen.

2.Touch the song you want to play.

When you are listening to music, touch , to use another application. Your music continues to play. To return to the music controls, open the notification panel and then touch the song.

8.3.4 Adding Music to a Playlist

1. Touch a category on the music library screen.

2. In the list that appears, select the song you want to add to the playlist.

3. Touch and hold the song, and then touch Addto playlist in the options menu.

??? Touch Current playlist to add the song to an existing playlist.

??? Touch New to create a playlist and add the song to it.

8.3.5 Playing a Playlist

1.Touch the Playliststab on the music library screen.

2.Touch and hold the playlist you want to play.

3.Touch Playto play the playlist.

9 Google Services

Availability of Google applications, services, and features may vary according to your country or carrier. Please follow the local laws and regulations to use them.

When you turn on your mobile phone for the first time, touch a Google services such as Talk, Gmail, or Market, and you will be prompted to sign in to your Google account.

Ensure that your mobile phone has an active data connection (3G/Wi-Fi) before you sign in to your Google account.

If you already have a Google account, touch Sign in and enter your username and password.

9.1 Creating a Google Account

If you do not have a Google account, you can create one:

1.After reading the setup information, touch Next.

2.Touch Create.

3.Enter a first name, last name, and user name for your Google account, and then touch Next. The mobile phone will connect to the Google server to check whether theusernameisavailable.Iftheusernameyouenteredisalreadyinuse,youwillbe prompted to choose another one or select one from a list.

4.Enter and confirm your Google account password.

5.Select a security question from the drop down menu, and then enter the answer.

6.Touch Create.

7.When the GoogleTermsofServicescreen appears, touch Iagree, Next.

8.Enter the characters that appear on the screen, and then touch Next.

To use another Google account, go to the Accounts & sync settings screen, and touch Add account to select which type of accounts you want to add.

9.2 Using Gmail

Gmail is Google???s web-based email service. When you first set up your phone, you may have configured it to use an existing Gmail account or create a new account. The first time you open the Gmail application on your phone, your Inbox will contain the messages from your Gmail account on the web.

your mobile phone will go to your Inbox folder.

9.2.2 Switching Between Accounts

1.In the mail list, touch , and then touch Accounts.

2.Touch the account that contains the email you want to read.

9.2.3 Creating and Sending an Email

1.In the mail list, touch , and then touch Compose.

2.Enter the message recipient???s email address in the To field. If you are sending the email to several recipients, separate the email addresses with commas. You can add as many message recipients as you want.

If you want to send a copy (Cc) or a blind copy (Bcc) of the email to other recipients, touch , and then touch Add Cc/Bcc.

3. Enter the email subject and write your message.

If you want to add a picture attachment, touch , and then touch Attach to select the picture you want to attach.

4. After composing your email, touch .

9.2.4 Replying To or Forwarding an Email

1. In the mail list, touch the email that you want to reply to or forward.

2. Touch to reply. You can also touch , and then touch Reply, Replyall, or

Forward.

3. Do one of the following:

???If you selected Reply or Reply all, enter your message.

???If you selected Forward, specify the message recipients and add any additional text you want to include with the forwarded message.

4.Touch to send, or touch to save as a draft.

9.2.5 Searching for an Email

1.In the mail list, touch , and then touch Search.

2.Enter the search keywords in the box, and then touch .

9.2.6 Customizing Your Gmail Settings

In the mail list, touch , and then touch More > Settingsto customize your Gmail.

9.3 Using Talk

Talk is Google???s instant messaging service. You can use it to communicate in real time with other people using Talk on a phone or on the web.

9.3.1 Opening Talk

Touch > Talk to open the application.

Your Talk account is based on the Google account you set up with your mobile phone.

9.3.2 Adding a Friend

1. In the friends list, touch , and then touch Addfriend.

2. EntertheTalkinstantmessagingIDorGoogleemailaddressofthefriendyouwant

to add.

3. Touch Sendinvitation.

9.3.3 Accepting an Invitation

1.If you have invited anyone to chat or if someone else has invited you to chat, this information will appear in the friends list.

2.Touch a pending invitation, and then touch Accept.

9.3.4 Starting a Chat

1. In the friends list, touch a friend's name in the friends list.

2. Use the onscreen keyboard to enter text and chat with your friend. 3. After entering your message, touch Send.

9.3.5 Setting Notifications for New Instant Messages

Whenever you receive an instant message, your mobile phone can play a sound, vibrate, or display an icon. To set up one of these handy notifications, start in the

friends list, and then touch . Then touch Settings. Now choose from one of the following:

9.3.6 Signing Out of Talk

In the friends list screen, touch , and then touch Sign out to quit Talk.

9.4 Using Maps

Maps lets you find your current location, view real-time traffic conditions (depending on availability in your locale), and get detailed directions to various destinations on a satellite, traffic, or other kind of map.

9.4.1 Enabling Location Source

Before you open Maps to find your location or search for places of interest, you must enable "location source".

1.Touch > Settings.

2.Touch Location&security.

3.In the MyLocationsection, select the Usewirelessnetworkscheck box, Use GPSsatellitescheck box, or both.

9.4.2 Opening Maps

Touch > Maps to open the application.

9.4.3 Searching for Places of Interest

3. Your search results will then be displayed. Touch a place you are interested in and the application will show where it is on the map.

9.4.4 Getting Directions

1.While viewing a map, touch , and then touch Directions.

2.Enter the starting point in the first text box, and then enter your destination in the second text box.

3.Touch the icon for car, public transit, or walking directions.

4.Touch Go. Your directions will appear in a list.

5.Touch a direction item on the list to show it on the map.

6.When you finish viewing or following the directions, touch and touch Clear Mapto reset the map.

9.5 Using YouTube

YouTube is Google???s free online video streaming service for viewing, searching for, and uploading videos.

9.5.1 Opening YouTube

Touch > YouTube. You will then see the YouTube screen.

9.5.2 Searching for a Video

3. You will see a number of search results displayed below the notification bar. Scroll through the results and touch a video to watch it.

9.5.3 Sharing a Video

From the video list on the YouTube screen, select a video clip and touch More >

Share.

9.6 Using Market

Android Market provides direct access to applications and games which you can download and install on your phone.

2. When you open Marketfor the first time, the Android MarketTermsof Service window will appear. Touch Accept to continue.

9.6.2 Searching for Applications

There are a few different ways to find applications on the Market home screen, including:

???Featured applications.

???List of games.

???Search function.

???My apps.

9.6.3 Installing an Application

If you want to install a non-Market application, touch > Settings > Applications, and then select the Unknown sources check box to allow installation of the non-Market application.

1.In the Market, touch Apps.

2.Touch a category, and then touch the item you want to download.

3.On the item details screen, read more about the application, including its cost, overall rating, and user comments. If you scroll down to the DeveloperInfo section, you can see other applications from the same developer, link to the developer's website, or send the developer an email.

4.To install the item, touch FREE > OK(if the item is free) or Buy, whichever is displayed.

5.Tochecktheprogressofadownload,openthenotificationpanel.Mostapplications are installed within seconds. To stop an item from downloading, touch Cancel.

6.Aftertheapplicationhasbeendownloadedandinstalledonyourmobilephone,the content download icon appears in the notification bar.

9.6.4 Uninstalling an Application

1.On the Market screen, touch Myapps.

2.Touch the application you want to uninstall, and then touch Uninstall.

3.When prompted, touch OKto remove the application from your mobile phone.

4.Choose the reason for removing the application, and then touch OK.

10 Synchronizing Information

Some applications on your mobile phone give you access to the same personal information that you can add, view, and edit on your computer. If you add, change, or delete your information in any of these applications on the web, the updated information also appears on your mobile phone.

This is made possible through over-the-air data synchronization. The process occurs in the background and does not interfere with use of your mobile phone. When your phone is synchronizing, a data synchronization icon will be shown in the notification bar.

10.1 Managing Your Accounts

You can synchronize contacts, email, and other information on your mobile phone with multiple Google accounts or other kinds of accounts, depending on the applications installed on your mobile phone.

For example, you can start by adding your personal Google account, so your personal email, contacts, and calendar are always available. You could then add a work account, so your work-related emails and work contacts are handy. If you like, you may add multiple Google accounts or other accounts.

10.1.1 Adding an Account

When you add an account, Contacts compares contacts from the newly synchronized account with contacts from your existing mobile phone accounts and attempts to merge duplicates into a single entry in Contacts. While it is presented as a single contact entry, the contact data itself is not merged.

1. Touch > Settings> Accounts&sync. The screen displays your current synchronization settings and a list of your current accounts.

In some cases, you may need to obtain account details from an IT support. For example, you may need to know the account???s domain or server address.

2.Touch Addaccount.

3.Touch the kind of account to add.

4.Follow the onscreen steps to enter the required and optional information about the account.Most accountsrequire ausername and password,butthe details depend

on the kind of account and the configuration of the service to which you are connecting.

5.Configure the account. Depending on the kind of account, you may be asked to configure what kind of data you want to sync to the mobile phone, to name the account, and for other details. When you are finished, the account is added to the list in the Accounts&syncsettings screen.

10.1.2 Removing an Account

Youcanremoveanaccount,deletingitandallinformationassociatedwithitfromyour mobile phone, including email, contacts, settings, and so on. You cannot, however, remove some accounts, such as the first account you signed into on the mobile phone.Ifyouattempttoremovecertainaccounts,all personalinformationassociated with it will be deleted.

You can onlyremove aGmailaccountby resettingthephone tofactorydefaults.

1.On the Accounts&syncsettingsscreen, touch the account to delete.

2.Touch Removeaccount.

3.Confirm that you want to remove the account.

10.2 Customizing Your Account

Synchronization

You can configure background data use and synchronization options for all the applicationsonyourphone.Youcanalsoconfigurewhatkindofdatayousynchronize for each account.

For some accounts, synchronizing is two-directional; changes that you make to the information on your mobile phone are made to the copy of that information on the web. Some accounts support only one-way synchronize; the information on your mobile phone is read-only.

10.2.1 Configuring General Sync Settings

On the Accounts & sync settings screen, do the following:

???Select or clear the Background data check box to control whether applications and services can transmit datawhen you arenotworking withthem directly(thatis, when they are running in the background).

If you clear this option, Gmail stops receiving new mail, Calendar stops synchronizingevents,andsoon,untilyoutouchtheRefreshmenuitemorsend an email.

???Select or clear the Auto-sync check box to control whether changes you make to information on the phone or on the web are automatically synchronized with each other.

For example, when this option is selected, changes that you make in Contacts on the phone are automatically made in Google Contacts on the web.

10.2.2 Changing an Account???s Synchronization Settings

1.On the Accounts&syncsettingsscreen, touch the account whose synchronizationsettingsyouwanttochange.Thedataandsynchronizationscreen opens, displaying a list of the kinds of information the account can synchronize.

2.Selected items are configured to synchronize to your mobile phone.

3.Select or clear the check box of information you want to synchronize to the mobile phone.

11 Using Other Applications

11.1 Using All Backup

You canback up datausing AllBackup.It provides the following options: Backupto SD, Restore from SD, and Quick Backup.

11.1.1 Backing up data by using Backup to SD

1.On the Home screen, touch > All Backup.

2.Touch Backup toSD.

3.Enter a file name in the Filename: field.

4.In the Backupcontents:field, select the contents you want to back up.

5.Touch Backup to back up the selected data.

To cancel the backup, touch Cancel.

11.2 Using the Calendar

Use Calendar to create and manage events, meetings, and appointments. Depending on your synchronization settings, the calendar on your phone can be synchronized with the internet-based calendar you use.

11.2.1 Opening the Calendar

Touch > Calendar to open the application.

To access Google calendar, touch , and then touch More > Calendars.

11.2.2 Creating an Event

1.On any calendar view, touch . Then touch Newevent to open the Event details screen.

2.Enter the event name.

???If there is a time frame for the event, touch From and To to set the beginning and end times of the event.

???If the event is a special occasion such as a birthday or a day-long activity, set the date for From and To, and then select the All day check box.

3.Enter the location of the event and a description.

4.If you have more than one calendar, select the calendar where you want to save the event.

5.Enter email addresses to invite guests to the event.

6.Set the time of your event reminder in Reminders, and then specify in Repetition whether the event recurs and, if it does, how frequently.

7.Touch Done.

To quickly create an event in theDay, Week, or Month view, touch and hold an empty time slot, and then touch New event. A new event details screen will

appear with the selected time slot and date in the From and To fields.

11.2.3 Setting an Event Reminder

1. On any calendar view, touch an event to view its details or an event summary.

2. Touch the Addreminder button to add a reminder. Or touch the reminder???s ???-??? button to delete an existing reminder.

3. Touch the reminder time, and then touch the length of time before the event when you want to be reminded. When the time comes, you will receive a notification about the event.

11.2.4 Setting the synchronize and display

1. On any calendar view, touch . Then touch More> Calendars.

The Calendars screen displays all the calendars you have added or subscribed to for each account that is configured to synchronize events to your phone, organized by account. (Calendars for accounts you have configured not to synchronize Calendar events are not included in the list.)

2.Touch the icon next to a calendar to change whether it is synchronized and whether it is displayed.

You remain subscribed to Calendars that you configure not to store on the phone and you can still work with them with Google Calendar on the web.

3. Touch OK.

11.2.5 Customizing the Calendar Settings

On any calendar view, touch . Then touch More > Settings.

???Hide declined events: Select to hide events for which you have declined invitations.

???Usehometimezone:Displayscalendarsandeventtimesinyourhometimezone when traveling.

???Selectringtone: Touch to select the ringtone to sound when you receive an event reminder.

???Vibrate: Select to vibrate the mobile phone when you receive an event notification.

???Default reminder time: Touch to select the default time before an event for event reminders to occur.

11.3 Using the Clock

In addition to displaying the date and time, the Clock application displays information about the weather and your phone. You can also use Clock to turn your mobile phone into an alarm clock.

11.3.1 Opening the Clock

Touch > Clock to open the application.

ClockopenswiththedateandtimedisplayedonyourHomescreenwallpaper,along with your local weather and other useful information.

11.3.2 Opening the Alarms

On the Clock screen, touch to open the Alarms.

Adding an Alarm

1.On the alarm list screen, touch Addalarm.

2.Set the alarm, and then touch Done.

Setting an Alarm

1.On the alarm list screen, touch one of the alarms on the screen.

2.Touch Time to set the time of the alarm.

3.Touch Repeat to set the days when you want the alarm to sound.

4.Touch Ringtoneto select a ringtone for the alarm.

5.Select the Vibrate check box to have the phone vibrate, in addition to playing the ringtone.

6.Touch Label to enter a name for the alarm.

7.Touch Done.

Customizing Alarm Settings

On the alarm list screen, touch , and then touch Settings.

11.4 Using the File Manager

File Manager is like having a pocket-sized personal assistant (PA), letting you organize, edit, and delete files and folders.

1. On the FileManager screen, access the directory of the folder you want to create. 2. Press to open the options panel, and then touch More > Newfolder.

3. Enter the name of the new folder in the text box.

4. Touch Save.

11.4.3 Moving or Copying a File

1.On the FileManager screen, press to show the options panel, and then touch Cutor Copy.

2.Touchthefileorfolderyouwanttomoveorcopy.Whenselected,acheckmarkwill appear.

To select all files, press to open the options panel. Then touch Selectall to select all files in a folder (touch Unselect all to cancel the selection).

3.Press to open the options panel, and then touch Doneto cut or copy the file.

4.Now select the path to where you want the file to be copied or moved. Press to open the options panel, and then touch Pasteto move or copy the file to the selected path.

11.4.4 Doing a Quick Search for a File

1.On the FileManager screen, touch a folder to access the directory where the file you want is located.

2.Press to open the options panel, and then touch Search.

3.Write a key word of the name of your file or folder in the search box.

4.Touch . Your mobile phone will start the search.

5.A list of search results will be displayed. Touch a file in the list to open it.

6.Touch Newsearchfor a new search or press the back key to return to the file manager screen.

11.4.5 Compressing or Extracting Files

Your phone supports compressing and extracting files.

You can only compress files and folders into .zip files, but can extract both .zip and .rar files.

Compressing Files

1.On the FileManager screen, Touch , and then touch Compress.

2.Select the files or folders you want to compress. When a file is selected, a check mark will appear.

To select all files and folders, Touch > Select all. Touch Unselect all to cancel the selection.

3.Touch > Done.

4.Edit the save path and the name of the target file, and then touch OKto start compressing the files and folders.

Extracting a File

1.Touch and hold a compressed file.

2.Touch Extract.

3.Edit the save path for extracted files.

4.Touch OKto start extracting.

11.4.6 Viewing Your Memory Status

On the File Manager screen, press to open the options panel, and then touch More > Memory Status. The memory management screen will be displayed. This screen allows you to view the memory status and available memory on your mobile phone and microSD card.

11.5 Using the Calculator

Use the calculator to solve simple arithmetic problems or use its advanced operators to solve more complex equations.

11.5.1 Opening the Calculator

Touch > Calculator to open the application.

11.5.2 Switching to the Advanced panel

On the Calculator screen, flick the screen to the right or left to switch between

Advanced panel and Basic panel.

11.6 Using the Richpad

Richpad combines text note and paint note functions. It lists all notes in a linear structure. You can add, edit, and delete notes.

You can touch any button on the screen to use the Richpad.

1.Touch > Richpadto open the application.

2.Touch , and then touch Add textnoteor Addpaint noteto create a note.

???While you are editing a text note, you can touch to change the background, change the font, or insert an icon.

???While you are editing a paint note, you can touch the icon on the upper right corner of the screen to draw a picture.

3.Touch the icons on the lower part of the screen to save the note, set the reminding, or discard the note.

12 Managing Your Mobile Phone

To configure your mobile phone, touch > Settings.

12.1 Setting the Date and Time

By default, your mobile phone automatically uses the date, time zone, and time provided by the network.

When your mobile phone is using date and time settings provided automatically by the network, you cannot manually set the date, time, and time zone.

12.2 Setting the Display

12.2.1 Adjusting the Screen Brightness

1. On the Settingsscreen, touch Display> Brightness.

2. Drag the slider left to make the screen darker, or right to make it brighter. 3. Touch OKto save the adjustment.

12.2.2 Adjusting the Time Before the Screen Turns Off

Ifyourmobilephoneisidleforseveral minutes,itwillturnoffthescreentosavebattery power. To set a longer or shorter idle time, do the following:

1.On the Settingsscreen, touch Display> Screentimeout.

2.Select the duration you want the screen to be illuminated.

12.3 Setting Ringers

12.3.1 Turning On Silent Mode

1.On the Settingsscreen, touch Sound.

2.Select the Silentmodecheck box to silence all sounds except alarms, and music and video media sound.

12.3.2 Adjusting the Volume

You can adjust the volume from the Home screen or any application screen (except during a call or when playing music or videos). Press the Volume keys to adjust volume to the level you desire.

You can also adjust the volume from the settings screen.

1.On the Settingsscreen, touch Sound> Volume.

2.Drag the slider left to make the volume lower, or right to make it higher.

3.Touch OKto save the adjustment.

12.3.3 Changing the Phone Ringtone

1. On the Settingsscreen, touch Sound> Phoneringtone.

2. Touch the ringtone you want to use, and then touch OK. The ringtone plays when

selected.

12.3.4 Changing the Message Ringtone

3. Touch the ringtone you want to use, and then touch OK. The ringtone plays when

selected.

12.3.5 Setting Your Phone to Vibrate for Incoming Calls

1.On the Settingsscreen, touch Sound.

2.Touch Vibrate, and then select one of the options.

12.4 Setting Phone Services

12.4.1 Customizing Call Settings

You mobile phone service provider offers different services such as call forwarding, call waiting, fixed dialing numbers, and voicemail. You can customize many of these services if they are part of your calling plan.

On the Settings screen, touch Call settings to customize your call functions.

12.4.2 Turning on Data Roaming

1.On the Settingsscreen, touch Wireless&networks> Mobilenetworks.

2.Select the Dataroamingcheck box.

Accessing data services while roaming may incur additional charges. Ask your wireless service provider about data roaming fees.

12.4.3 Switching off the Data Service

1.On the Settingsscreen, touch Wireless&networks> Mobilenetworks.

2.Clear the Dataenabledcheck box.

12.5 Setting Text-to-Speech

Use the Text-to-Speech settings to configure the Android text-to-speech synthesizer, for applications that can take advantage of this feature.

12.5.1 Installing Voice Data

1. On the Settingsscreen, touch Voiceinput &output> Text-to-speechsettings

> Install voicedata.

2. If your mobile phone does not have speech synthesizer data installed, connect to Android Market and let it guide you through the process of downloading and installing the data.

3. Follow the instructions to install the voice data.

12.5.2 Adjusting the Speech Rate

1.On the Settingsscreen, touch Voiceinput &output> Text-to-speechsettings > Speechrate.

2.Select a speed at which the text is to be spoken.

12.6 Protecting Your Mobile Phone

12.6.1 Protecting Your Mobile Phone with a Screen Lock Pattern

To keep your data more secure, lock the screen and/or require a screen unlock pattern every time your mobile phone is turned on or wakes up from sleep mode.

1.On the Settingsscreen, touch Location&security > Setupscreenlock> Pattern.

2.Flicking your finger vertically, horizontally or diagonally, connect at least four dots in any order you choose. Lift your finger from the screen when you are finished.

You must flick your finger on the screen to create the pattern, not simply touch individual dots.

3.Your mobile phone will record the pattern. Touch Continue.

4.When prompted, draw the screen unlock pattern again, and then touch Confirm.

Tochangeyourunlockscreenpattern,touchLocation&security>Changescreen lock.

12.6.2 Protecting Your Mobile Phone with a numeric PIN

You can set up a numeric PIN to lock your phone.

1.On the Settingsscreen, touch Location&security > Setupscreenlock> PIN.

2.Enter at least four characters.

3.Touch Continue.

4.Enter the same characters again and touch OK.

To change your PIN, touch Location & security > Change screen lock.

12.6.3 Unlocking Your mobile phone if you forget the lock pattern

If you have already created a Google account, you can unlock your mobile phone by the following methods.

???After you have entered the wrong sequence five times, a Forgot pattern? button willappear.Touch thisbutton to enter theGoogle accountinterface.Afteryouhave enteredyourGoogle accountpassword,you will beabletoresettheunlock pattern.

???After you have entered the wrong pattern twenty times, you will be taken directly to the Google account interface. After you have entered your Google account password, you will be able to reset the unlock pattern.

12.7 Managing Applications

12.7.1 Viewing an Installed Application

1. On the Settingsscreen, touch Applications> Manageapplications. 2. In the applications list, do any of the following:

12.7.2 Uninstalling an Application

1.On the Settingsscreen, touch Applications> Manageapplications.

2.Touch an application, and then touch Uninstall.

YoucanalsotouchandholdanitemontheHomescreenuntiltheSelectaction menu is displayed, and then touch Uninstall application to uninstall the application.

12.7.3 Moving an Application to microSD card

Some applications are designed to be stored on your phone???s USB storage or SD card (depending on your model of phone), rather than in internal storage. Others are designed so you can change where they are stored. You may find it helpful to move large applications off of your internal storage, to make more room for other applications that don???t offer the option.

1. On the Settingsscreen, touch Applications> Manageapplications.

2.Touch an application in the list. Then touch MovetoSDcardto move the bulk of the application from the phone???s internal storage.

The Storage section of the application???s details screen shows details about the memory used by the application. If the application can be moved, the Move button is active.

Touch Move to phone to move the application back to the phone???s internal storage.

12.7.4 Ways to Free Up Your Mobile Phone Memory

???Move files and email attachments to the microSD card.

???In Browser,clear all temporary Internet filesand Browser historyinformation.

???Move application to microSDcard.

???Uninstall any downloadedprogramsthatyouno longer use.

???Reset yourmobile phone.

12.8 Resetting Your Mobile Phone

12.8.1 Backing Up My Data

You can use your Google account to back up your mobile phone???s settings to Google servers. If you replace your mobile phone, the settings you have backed up will be transferred to the new mobile phone the first time you sign in to your Google account.

1.On the Settingsscreen, touch Privacy.

2.Select the Backupmydatacheck box.

12.8.2 Restoring Factory Data

If you reset your phone to the settings that were configured at the factory, all of your personal datastoredonthe phone,includinginformation aboutyourGoogleAccount, any other accounts, your system and application settings, and any applications you have downloaded will be erased. Resetting the phone does not erase any system software updates you have downloaded or any files on your microSD card, such as music clips or photos.

1. On the Settingsscreen, touch Privacy> Factorydatareset.

2.When prompted, touch Reset phone, and then touch Eraseeverything. The mobile phone resets the settings to the original factory settings, and then restarts.

12.9 Online Update

Your mobile phone has pre-installed the online update function. When there is new software available, the version information appears and prompts you to update. You can also touch Settings > About phone > Software Update to check whether the new software is available.

1.Back up you personal information. All personal information will be removed after the update.

2.Make sure that your microSD card has sufficient space to store the new software version.

3.Perform the online update following the on-screen instructions.

13 Appendix

13.1 Warnings and Precautions

This section contains important information pertaining to the operating instructions of your device.Italsocontainsinformationabouthowto usethedevicesafely.Readthis information carefully before using your device.

Electronic Device

Power off your device if using the device is prohibited. Do not use the device when using the device causes danger or interference with electronic devices.

Medical Device

???Followrules and regulationsset forth byhospitalsand health care facilities. Do not use your device when usingthedevice isprohibited.

???Pacemaker manufacturersrecommend thata minimum distanceof 5.9 inches (15 cm) be maintained betweena device and a pacemaker to prevent potential interference with the pacemaker.Ifyou areusing a pacemaker, use the device on the opposite side of the pacemaker anddo notcarry the device in your front pocket.

???Some wireless devicesmayaffect the performance ofhearing aids.For any such problems, consultyour service provider.

???To ensure thatthe HearingAid Compatibility rating for yourdevice ismaintained, secondarytransmitterssuchasBluetoothandWi-Ficomponentsmustbedisabled during a call.

Potentially Explosive Atmosphere

Power off your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. Areas that may have potentially explosive atmospheres include the areas where you would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your device at refueling pointssuchasservicestations.Complywithrestrictionsontheuseofradioequipment infueldepots,storage,anddistributionareas,andchemicalplants.Inaddition,adhere to restrictions in areas where blasting operations are in progress. Before using the device,watchoutforareasthathavepotentiallyexplosiveatmospheresthatareoften,

butnotalways,clearlymarked.Suchlocationsincludeareasbelowthedeckonboats, chemical transfer or storage facilities, and areas where the air contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles usingliquefiedpetroleumgas(suchaspropaneorbutane)whetherthisdevicecanbe safely used in their vicinity.

Traffic Security

Observe local laws and regulations while using the device. In addition, if using the device while driving a vehicle, comply with the following guidelines:

???Concentrate ondriving. Your first responsibility is to drivesafely.

???Do nottalk on the device while driving. Use hands-free accessories.

???When you have to make oranswer a call, parkthevehicle at the road side before using yourdevice.

???RF signals mayaffectelectronicsystemsofmotor vehicles.For more information, consult the vehicle manufacturer.

???In a motor vehicle,do not place the device overtheair bag or in the air bag deploymentarea. Otherwise,the devicemay hurtyou owing tothe strong force when the airbag inflates.

???Do notuse your device whileflying in anaircraft. Power offyour device before boarding an aircraft.Using wirelessdevicesin an aircraft may cause dangerto the operation of the aircraft and disrupt the wirelesstelephone network. It may also be considered illegal.

Operating Environment

???Do notuse or charge the device in dusty,damp, and dirtyplaces or placeswith magnetic fields. Otherwise,it mayresultin a malfunction ofthe circuit.

???The device complieswith the RFspecifications when the device isused near your ear or at a distance of0.59 inch (1.5 cm) from your body.Ensure thatthe device accessoriessuchasadevicecaseandadeviceholsterarenotcomposedofmetal components.Keep yourdevice 0.59 inch(1.5 cm) away fromyour body to meet the requirementearlier mentioned.

???On astormydaywith thunder,do not use yourdevice whenit isbeing charged, to preventanydanger caused bylightning.

???Whenyouareonacall,donottouchtheantenna.Touchingtheantennaaffectsthe call quality and resultsin increase in powerconsumption.Asa result, the talktime and the standby time are reduced.

???While using the device, observe the local lawsandregulations, and respectothers' privacyand legal rights.

???Keep the ambienttemperature between 32??F (0??C)and 113??F (45??C) while the device is being charged.Keep the ambienttemperature between32??F (0??C)to 113??F (45??C)forusing the device powered bya battery.

Prevention of Hearing Damage

Using a headset at high volume can damage your hearing. To reduce the risk of damage to hearing, lower the headset volume to a safe and comfortable level.

Safety of Children

Comply with all precautions with regard to children's safety. Letting the child play with yourdeviceoritsaccessories,which mayincludepartsthatcan be detachedfromthe device, may be dangerous, as it may present a choking hazard. Ensure that small children are kept away from the device and accessories.

Accessories

Chooseonlybatteries,chargers,andaccessoriesapprovedforusewiththismodelby the device manufacturer. The use of any other type of battery, charger, or accessory may invalidate any warranty for the device, may be in violation of local rules or laws, and may be dangerous. Please contact your dealer for information about the availability of approved batteries, chargers, and accessories in your area.

Battery and Charger

???Unplug the chargerfrom the electrical plug and the device when notin use.

???The battery can be charged anddischargedhundredsoftimes before it eventually wearsout.When the standby time and the talk time are shorter thanthe normal time, replace the battery.

???Use the AC power supplydefinedinthespecifications ofthe charger.An improper powervoltage may cause a fire or a malfunction ofthe charger.

???Do notconnect two polesofthe batterywith conductors, such asmetal materials, keys,or jewelries.Otherwise, the battery maybe short-circuitedand maycause injuries and burnson yourbody.

???If battery electrolyte leaks out,ensure that the electrolyte does not touch yourskin and eyes. When theelectrolyte touches yourskin orsplashesintoyour eyes,wash your eyes with clean water immediately and consult a doctor.

???If there is a case ofbatterydeformation, colorchange, orabnormal heating while you charge or storethebattery, remove the batteryimmediatelyand stop using it. Otherwise,it maylead to battery leakage, overheating, explosion, orfire.

???If the power cable is damaged (for example, the cord is exposedor broken), orthe plugloosens, stop using the cable at once.Otherwise, itmaylead to an electric shock,a shortcircuit ofthe charger,or afire.

???Do notdispose ofbatteriesin fire asthey mayexplode. Batteriesmay also explode ifdamaged.

???Do notmodify or remanufacture,attempt to insert foreign objects into the battery, immerse or expose to wateror other liquids,expose to fire, explosion or other hazard.

???Avoid dropping thedevice or battery. If thedevice or batteryis dropped,especially on ahard surface, and the user suspectsdamage,take itto aqualified service center forinspection.

???Improper battery use mayresultin a fire,explosion orother hazard.

???Promptlydispose of used batteriesin accordance with local regulations.

???The device should onlybe connected to products thatbear the USB-IFlogo or have completedtheUSB-IFcompliance program.

???Onlyusethebatterywithachargingsystemthathasbeenqualifiedwiththesystem per this standard,IEEE-Std-1725-2006.Use ofan unqualified battery orcharger maypresent a riskoffire, explosion, leakage, or otherhazard.

???Replace the batteryonlywith another battery thathasbeen qualified withthe systemper thisstandard,IEEE-Std-1725-2006. Use of an unqualified batterymay presenta risk offire,explosion, leakage orother hazard.

Cleaning and Maintenance

???The device,battery, and charger are not water-resistant.Keep them dry.Protect thedevice,battery,andchargerfromwaterorvapor.Donottouchthedevice orthe charger witha wethand.Otherwise, itmay lead to a shortcircuit,a malfunction of the device, and anelectric shock to the user.

???Do notplace your device,battery, and charger in places wherethey can get damaged because of collision. Otherwise, it may lead to batteryleakage, device malfunction,overheating, fire, orexplosion.

???Do notplace magneticstorage media suchas magnetic cards and floppydisks near the device.Radiation from the device may erase the information stored on them.

???Do notleave your device,battery, and charger in a placewith an extremehigh or lowtemperature.Otherwise, theymaynotfunction properlyand mayleadto afire oran explosion.When the temperature islower than 32??F (0??C), performanceof the battery is affected.

???Do notplace sharpmetal objectssuch as pins near the earpiece.The earpiece mayattractthese objects and hurt you whenyou are using thedevice.

???Before you cleanor maintainthedevice,poweroffthe device and disconnectit from the charger.

???Do notuse anychemical detergent, powder,or other chemical agents(suchas alcohol and benzene) to clean the device and the charger.Otherwise, parts of the device maybedamagedorafire canbecaused.Youcanclean thedevice andthe charger witha piece ofdamp and softantistaticcloth.

???Do notdismantle the device or accessories.Otherwise, the warrantyon the device and accessoriesis invalid and the manufacturer is not liable to payfor the damage.

???If the device screen isbroken by colliding with hard objects, do not touch ortry to remove the brokenpart.In thiscase,stopusing the device immediately,and then contact anauthorized service center in time.

Emergency Call

You can use your device for emergency calls in the service area. The connection, however, cannot be guaranteed in all conditions. You should not rely solely on the device for essential communications.

Certification Information (SAR)

This device meets guidelines for exposure to radio waves.

Your device is a low-power radio transmitter and receiver. As recommended by internationalguidelines,thedeviceisdesignednottoexceedthelimitsforexposureto radio waves. These guidelines were developed by the independent scientific organization International Commission on Non-Ionizing Radiation Protection

(ICNIRP) and include safety measures designed to ensure safety for all users, regardless of age and health.

The Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio frequency energy absorbed by the body when using a device. The SAR value is determined at the highest certified power level in laboratory conditions, but the actualSARlevel ofthedevicewhen being operated canbe well belowthe value.This is because the device is designed to use the minimum power required to reach the network.

The SAR limit adopted by USA and Canada is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue. The highest SAR value reported to the FCC and IC for this device type when tested for use at the ear is 1.34 W/kg, and when properly worn on the body is 1.02 W/kg, and when using Wi-Fi hotspot function is 1.32 W/Kg.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to providereasonableprotectionagainstharmfulinterferencein aresidential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Caution

Changes or modifications made to this device not expressly approved by Huawei Technologies Co., Ltd. may void the FCC authorization to operate this device.

Hearing Aid Compatibility (HAC) regulations for Mobile phones

In 2003, the FCC adopted rules to make digital wireless telephones compatible with hearing aids and cochlear implants. Although analog wireless phones do not usually cause interference with hearing aids or cochlear implants, digital wireless phones sometimes do because of electromagnetic energy emitted by the phone's antenna, backlight, or other components.

Your phone is compliant with FCC HAC regulations (ANSI C63.19).

While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise.

Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box. The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully.Tryingoutthephonewithyourhearingdeviceisthebestwaytoevaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usablewithahearingdevice???stelecoil(???TSwitch???or???TelephoneSwitch???)thanunrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.) Hearing devices may also be measured.

Your phone meets the M4/T3 level rating. Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating.

For more information about the FCC Hearing Aid Compatibility please go to http://www.fcc.gov/cgb/dro.

13.2 FAQ

How do I set a song as phone ringtone?

Touch and hold the song to be set as ringtone, and then touch Use as phone ringtone.

How do I prevent automatic switching of orientation when rotating phone?

How can I change the keyboard mode?

Touch and hold the area where you write text and then select the input method you prefer.

How do I stop the song playing in the background?

Touch the notification bar, flick downwards to open the notifications panel, and then touch the music playing notification to go to the music playing screen.

How do I return to the calling screen?

While on a call, if you???re on another screen, you can touch the notification bar, and drag downwards to open the notifications panel. Then touch the current call notification to return to the calling screen.

How do I create an application shortcut on the Home screen?

Touch and hold an application icon on the main menu screen until the Home screen is displayed. Then drag the icon where you want it to go and release your finger.

How do I hide the keyboard?

Touch to hide the keyboard.

How do I forward a message?

Touch and hold a message, and then touch Forward in the menu that opens.

Why am I unable to use Navigation?

Navigation is unavailable in some countries or regions.
