Copier Bulletin: DIG-61
Date: 11/01/01
Page: 1 of 3
Models: e-STUDIO 28
Subject: SERVICE DOCUMENTATION
Because the design of the e-STUDIO28 is based on the e-STUDIO35/45, a new service manual will not be created. This bulletin describes the primary differ- ences between the models.
In the tables below, the first number refers to the e-STUDIO45, the bracketed
[ ] number refers to the e-STUDIO35, and the number in parens { } refers to the e-STUDIO28.
SERVICE MANUAL
(more)
Copyright-2001 Toshiba America Business Solutions, Inc. (TABS). This publication contains proprietary and confidential information retained for reference purpose by authorized TABS dealers. Unauthorized use of this information is prohibited. TABS makes no express or implied warranty, including implied warranties of merchantability for a particular purpose, with regard to this technical publication and disclaims any claim arising by reason of the possesion or use thereof.
SERVICE HANDBOOK
1. Error code and self-diagnosis 1.2.3 Setting mode (08)
Code 251: PM counter setting value (default value)
e-STUDIO45 : 150,000
e-STUDIO35 : 120,000
e-STUDIO28 : 93,000
3. Preventive Maintenance (PM)
