Declaration of conformity for the European Community

Telefield NA. declares that RCA IP060S telephone complies with the relevant basic requirements and

provisions of the European directive 1999/5/CE. You can download the declaration of conformity and the user???s guide from the following address: www.rca4business.com

The CE logo shown on the products indicates that they are compliant with the basic requirements of all the applicable directives.

Environment

This symbol means that your inoperative electronic appliance must be collected separately and not mixed with the household waste. The European Union has implemented a specific collection and recycling system

for which producers' are responsible.

This appliance has been designed and manufactured with high quality materials and components that can be recycled and reused.

Electrical and electronic appliances are liable to contain parts that are necessary in order for the system to work properly but which can become a health and environmental hazard if they are not handled or disposed of in the proper way. Consequently, please do not throw out your inoperative appliance with the household waste. If you are the owner of the appliance, you must deposit it at the appropriate local collection point or leave it with the vendor when buying a new appliance.

IP160S

Quick start guide

Left soft key:

access to call list

Right soft key:

access to calendar

Navigation key: main menu/OK key

Left: phonebook

Right: volume control

Up: redial

Down: intercom

BLF key

End call

Power on/off

Accept calls

Handsfree mode

Select line

Hash key:

change text input method (upper case/lower case)

Voicemail key

Star key: lock/unlock keypad

Mute key:

mute/unmute

302

Display icon description

Base led description

Phone web interface

???Press to access main menu.

???Select Status Network Status. Check IP address.

???Open a web browser on your computer. Enter http:// and the IP address in the address bar and confirm.

???Default login and password are ???admin/0000??? for administrator and ???userx/0000??? for users, where x is handset number

???Minimum config is sip account. Select System SIP Account Management. Check administrator guide for details. Note: you can also configure sip account using handset keypad. Go to Menu Settings VoIP Account Setup

Making a call

Accepting a call

???Handset mode: press .

???Headset mode: press .

???Handsfree mode: press twice.

Putting a call on hold

???Select Hold with navigator and press .

???To retrieve the call, select Unhold with navigator and press . Note: with more than one active call, select call with Switch softkey .

3-party conference

Call transfer

Attended transfer:

???Once in line with 1st caller, press 2nd Call softkey, then select the type of call and press .

???Dial the second telephone number or select handset.

???When the call is answered, select Transfer from call options list to complete the transfer.

Blind transfer:

???Once in line with 1st caller, press Transfer softkey.

???Dial the destination telephone number and press Transfer soft key.

Call forward

???Press to open main menu. Select Services Call Forward.

???Select the line for which you want to set call forward.

???Then select the type of call forward.

???Set the status to enabled/disabled, fill in destination number and press .

Paging and Intercom

??? To locate your handsets, press the paging key on the base. Press again to cancel.

??? To make an internal call to another handset, press key, select the desired handset from the list and press .

Language selection

???Press to open main menu. Select Settings Language.

???Select the desired language and press .

Phonebook

Access phonebook :

??? Press .

???Select the Directory type.

???Select a contact and press Options soft key to select an operation.

Add new entry :

???Press .

???Select the Directory type.

?????? Select Options and press Add soft key to add a new entry.

???Enter first name, last name and numbers.

???Press Save soft key.

Redial

???Press .

???Highlight a record.

???Press to make the call, you may select the line by long pressing .

.

Do not Disturb

???Press , select ServicesDND.

???Select the line for which you want to set DND feature.

???Select Activate and press .

Voicemail

???Press to access voicemail.

OR

???Go to Menu Voicemail to check number of messages. Press Call softkey to retrieve your messages.
