Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you???ll receive all the information and special offers which you qualify for as the owner of your model.

Congratulations on your purchase, and welcome to the ???family!???

Know these

safetysymbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Dear product owner:

Thank you for your confidence in this product. You???ve selected one of the best-built, best-backed products available today. And we???ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the SV2000 ???family,??? you???re entitled to protection by one of the most comprehensive warranties and outstanding ser- vice networks in the industry.

What???s more, your purchase guarantees you???ll receive all the infor- mation and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly, you can count on our uncompromising com- mitment to your total satisfaction.

All of this is our way of saying welcome - and thanks for investing in an SV2000 product.

P.S. Remember, to get the most from your product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

For Customer Use

tThis ???bolt of lightning??? indicates uninsulated

material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering.

scalls attention to features for which you shouldThe ???exclamation point???

read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: TO PREVENT

FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS

EQUIPMENT TO RAIN OR

MOISTURE.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.

ATTENTION: Pour ??viter les chocs ??lectriques, intro- duire la lame la plus large de la fiche dans la borne corre- spondante de la prise et pousser jusqu???au fond.

Features

???Auto Return

???Auto Satellite Link

???Automatic Channel Setup

???Automatic Playback Features

???Automatic Tracking Adjustment

???Display Panel

???Hi-Fi Stereo Sound System

???High Quality (HQ) System

???MTS (Multi-Channel Television Sound) System

???On-Screen Displays in English or Spanish

???One-Touch Recording

???Real-Time Counter

???Remote Control

???Rental Play

???Repeat Play

???Special Effects Playback: Forward and Reverse Searching; Still; Slow

???Special Search Functions: Index; Time; Quick Find

???Timer Recording

Safety Precautions

Warning: To prevent fire or shock hazard, do not expose this equipment to rain or moisture.

FCC Warning: Any unauthorized changes or modifica- tions to this equipment void the user???s authority to oper- ate it.

This VCR, equipped with a High Quality (HQ) system, is compati- ble with existing Video Home System (VHS) equipment.

Philips Consumer Electronics Company recommends that you use only video cassette tapes that have been tested and inspected for use in two, four, six, and eight hour VCRs, and which are labeled

with the mark. The use of tapes that have not been inspected for use in two, four, six, and eight hour VCRs may result in poor picture quality and excessive deposits on the video heads, which may not be covered by the warranty if damage occurs.

Note to the Cable TV System Installer: This reminder is provided to call the Cable TV system installer???s attention to Article 820-40 of the National Electrical Code, which provides guidelines for proper grounding ??? in particular, specifying that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible.

Copyright 1998 Philips Consumer Electronics Company. All rights reserved.

Helpful Hint

???Before doing anything else, record the VCR???s model and serial numbers in the spaces provided on page two. These numbers will help us assist you if you ever call for help.

Putting Batteries in the Remote Control

1

Remove the battery compartment lid on the bottom of the remote control by sliding the lid in the direction of the arrow.

2

Insert two AA batteries inside the battery compartment with their + and ??? ends aligned as indicated.

3

Replace the battery compartment lid.

Using the Remote Control

???Point the remote control at the VCR???s remote sensor (see page

21)when using the remote control to operate the VCR.

???Do not put objects between the remote control and the VCR.

1

2

3

Erasure Prevention

Video cassette tapes have record tabs to ensure that recordings are not erased accidentally.

1

To prevent accidental erasure, break off the tab with a screwdriv- er.

2

To record again, cover the hole with cellophane tape.

VCR maintenance

???In this VCR, use only tapes with the mark.

???Make sure any light adhesive stick-on notes are removed from the video cassette tape before putting the tape in the VCR. Removable labels like these can jam the VCR.

???Periodic maintenance is required to maintain your VCR???s per- formance. The video heads will eventually require cleaning or replacement. Cleaning or replacement of the video heads should be performed by an authorized service center.

1

2

Helpful Hints

???The remote control and its batteries are supplied.

???Do not mix alkaline and man- ganese batteries.

???Do not mix old and new batteries.

CH3 / CH4

Switch

ANT

R

VIDEO

OUT

CH3 CH4

IN

OUT

RF coaxial cable

RF coaxial cable

TV???s

3 ANTENNAJack IN

1 VCR

Cable

Signal

2 Cable Box/DBS

3

Set the TV to the Cable Box/DBS output channel (03 or 04).

4

Select the channel you want to watch at the Cable

Helpful Hint

???When you play a tape, make sure the Cable Box/DBS is set to the same channel as the CH3/CH4 switch on the VCR. Set the TV to the Cable Box/DBS output channel (03 or 04).

3

??? Audio and Video cables are not supplied.

1

Connect the antenna or cable to the ANT(enna) IN Jack on the back of the VCR.

2

Connect a video cable to the yellow VIDEO OUT Jack on the back of the VCR. Then, connect the other end of the video cable to the VIDEO IN Jack on your TV.

3

Connect an audio cable to the red and white AUDIO OUT Jacks on the back of the VCR. Then, connect the other end of the audio cable to the AUDIO IN Jacks on your TV.

4

Turn on your TV, making sure it is in Line Input mode. Please refer to your TV owner???s manual for details.

Audio and Video

IN Jacks on TV

???Before turning on your VCR, make sure there are batteries in the remote control and the VCR and TV are connected (see pages five - 10).

???You can not set up channels if you are using a Cable Box/DBS.

???The instructions on this page only work when you turn on the VCR for the first time. If there is a power failure or if the VCR is unplugged for more than one minute, you may need to repeat the instructions on this page.

Turning on Your VCR 11

2Turn on the TV.

1

Press the POWER button. The POWER light and the VCR/TV light will appear.

2

Turn on the TV. Set it to the same channel as the CH3/CH4 switch on the back of the VCR. The menu shown

below will appear.

3

Press the PLAY button or the STOP button to select ENGLISH or ESPA??OL. [ON] will appear beside your choice.

4

Press the F.FWD button or the MENU button. TUNER SET UP will appear on-screen.

TUNER SET UP

5

Press the MENU button, the F.FWD button, or the REWIND button to begin automatic channel setup.

TUNER SET UP will flash on-screen. The VCR will memorize all available channels, so when you use the CHANNEL o/p buttons, you???ll only scan through channels that you receive. When channels are set up, the TV will go to the lowest channel available.

(If you try to set up channels when there is no antenna or cable connected to the VCR, programming will appear to take place. Eventually, TUNER SET UP will appear on-screen steadily, and channel programming will stop. Connect an antenna or cable to the VCR, then press the MENU button, the F.FWD button, or the REWIND button again. Channel programming will begin again.)

3

Helpful Hint

???If you do not see any on-screen dis- plays when you turn on the VCR, check your hookups, then try again. If you still do not see any on-screen displays, follow the steps under ???Automatic Channel Setup??? on page 12 and ???Language Selection??? on page 16.

12 Automatic Channel Setup

Although your VCR may automatically set up the channels you receive when you turn it on for the first time, this function lets you set up channels again. Make sure:

???The VCR is on and is in VCR position. (The VCR/TV light will appear on the display panel. If it does not, press the VCR/TV button once.)

1

Press the MENU button repeatedly until the INITIALIZE menu appears.

INITIALIZE

??? CHANNEL SET UP

SETTING CLOCK

LANGUAGE SELECT

2

Press the PLAY button or the STOP button repeatedly to select CHANNEL SET UP. Then, press the F.FWD but- ton.

3

Press the PLAY button or the STOP button repeatedly to point to TV (if you have an antenna) or CATV (if you have a cable connection).

4

Press the F.FWD button once or twice. [ON] will appear beside your selection, then the VCR will memorize all available channels. When setup is complete, the lowest channel you receive will appear on-screen.

POWERVCR/TV EJECT

34

Helpful Hints

???Line Input mode will always be stored in the VCR???s memory as channel 00. When you select chan- nel 00 with the CHANNEL o/p buttons or the Number buttons, AUX will appear on-screen.

???You can not program channels if you are using a Cable Box/DBS. Details are on pages eight - nine.

The channels you no longer receive or seldom watch can be deleted from the memory. You also may add new channels into the memory. Make sure:

???The VCR is on and in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

1

Press the MENU button repeatedly until the INITIALIZE menu appears.

2

Press the PLAY button or the STOP button repeatedly to select CHANNEL SET UP. Then, press the F.FWD but- ton.

3

Press the PLAY button or the STOP button repeatedly to select ADD/DELETE CH. Then, press the F.FWD button.

ADD / DELETE CH 0 2 (TV)

4

Press the Number buttons or press the PLAY button or the STOP button repeatedly until your desired channel number appears.

1

5

4

POWERVCR/TV EJECT

2-3

14 Setting the Clock

Follow the steps below to set your VCR???s clock. Make sure:

???The VCR is on and in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

1

Press the MENU button repeatedly until the INITIALIZE menu appears.

2

Press the PLAY button or the STOP button repeatedly to select SETTING CLOCK. Then, press the F.FWD button.

3

While the MONTH space is flashing, press the PLAY but- ton or the STOP button repeatedly until the desired month appears. Then, press the F.FWD button.

4

While the DAY space is flashing, press the PLAY button or the STOP button repeatedly until the desired day appears. Then, press the F.FWD button.

5

While the YEAR space is flashing, press the PLAY button or the STOP button repeatedly until the desired year appears. Press the F.FWD button. The day of the week will appear automatically.

POWERVCR/TV EJECT

2-5

Helpful Hints

???To reset the clock, follow steps 1 - 2 above. Select the information you want to change using the F.FWD button or the REWIND button. When the desired information is flashing, use the PLAY button or the STOP button to enter the correct information. Press the COUNTER RESET/EXIT button to exit.

???To display the time, press the DIS- PLAY button repeatedly until the time appears on-screen.

???Power failures that last for more than one minute can cause you to lose your clock setting.

???Press the REWIND button to go back one step from the current step during steps 4 - 8.

7

While the MINUTE space is flashing, press the PLAY but- ton or the STOP button repeatedly until the desired minute appears. Then, press the F.FWD button.

8

While the AM or PM space is flashing, press the PLAY but- ton or the STOP button repeatedly to point to AM or PM.

9

Press the COUNTER RESET/EXIT button or the F.FWD button to start the clock.

POWERVCR/TV EJECT

6-7

Helpful Hint

???If the clock has never been set, the SETTING CLOCK menu may appear immediately when you press the MENU button. If this happens, follow the instructions from step 3 on page 14.

16 Language Selection

Follow the steps below to change the language of the on-screen menus and displays. Make sure:

???The VCR is on and in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

1

Press the MENU button repeatedly until the INITIALIZE menu appears.

INITIALIZE

???CHANNEL SET UP

SETTING CLOCK

LANGUAGE SELECT

2

Press the PLAY button or the STOP button repeatedly to select LANGUAGE SELECT. Then, press the F.FWD but- ton.

INITIALIZE

CHANNEL SET UP

SETTING CLOCK

??? LANGUAGE SELECT

3

Press the PLAY button or the STOP button to select ENGLISH or ESPA??OL. [ON] will appear beside your choice.

LANGUAGE SELECT

1

3

POWERVCR/TV EJECT

4

2

Press the DISPLAY button once.

Helpful Hints

???If the channel you select has no broadcast, the screen will be solid blue.

???You may bring up a status display at any time by pressing the DIS- PLAY button. (The exception is when viewing a still picture or a slow motion picture, or when F.FWD or REWIND is pressed dur- ing playback.)

???Channel numbers (when tuned) appear on-screen for a few seconds.

POWER Button

Press to turn the VCR on or off.

Number Buttons

Use to select channels.

Channels 1 - 9 ???

To select, press 0, then press the channel number you want. For example, to select channel 7, press 0, 7.

Channels 100 and above ???

To select, press the +100 button, then press the last two digits of the channel you want. For example, to select channel 117, press the +100 button, 1, 7.

SPEED Button

Press to select the recording speed (SP, LP, or SLP). Details are on pages 24 and 45.

QUICK-FIND Button

Press to perform a Quick Find. Details are on page 40.

SLOW Button

Press during tape playback to view a tape in slow motion. Slow speed can be adjusted by pressing the F.FWD button (faster) or the REWIND button (slower). Details are on page 35.

MENU Button

Press repeatedly to access menus or to remove menus.

DISPLAY Button

Press repeatedly to view the on-screen status displays. Details are on page 17.

REWIND Button

When tape playback is stopped, press to rewind the tape at high speed. During tape playback, press to rewind the tape while the pic- ture stays on-screen. Details are on page 35.

Press to erase a timer recording. Details are on page 29. Press to go back one step when setting the clock or a timer recording.

Press to add or delete channel numbers. Details are on page 13.

RECORD Button

Press to start a recording. Details are on page 24.

PLAY Button

Press to play a tape. Also, press to release Slow, Search, or Still mode and to return to normal playback. Details are on page 35.

Use to enter digits and information when programming a function in the on-screen menu (setting the clock, for example). Press to select an item in the on-screen menu.

EJECT Button

Press to eject the tape.

VCR/TV Button

Use to select the signal that your TV receives.

??? VCR Position

Use to watch a tape, to watch a program while recording it, or to watch a TV broadcast using the CHANNEL o/p or Number buttons.

??? TV Position

Use to watch TV or to watch one program while recording anoth- er. Details are on page 32.

CHANNEL o/p Buttons

Press to scan up or down through the VCR???s channels after the channels have been set up. Details are on page 12.

During slow motion playback, press to adjust the tracking. Details are on page 41.

TIME SEARCH Button

Press to perform a Time Search. Details are on page 39.

INDEX SEARCH Button

Press to perform an Index Search. Details are on page 38.

COUNTER MEMORY Button

Press to memorize a tape position at which the real-time counter was set to 0:00:00. Details are on page 37.

COUNTER RESET/EXIT Button

Press to set the real-time counter to zero. Details are on page 37. Press to remove menus.

STOP Button

Press to stop the tape. Use to enter digits and information when programming a function in the on-screen menu (setting the clock, for example). Press to select an item in the on-screen menu.

PAUSE/STILL Button

During recording, press to temporarily stop the recording. Press again to resume recording. Details are on page 24. You can not pause a One-Touch Recording. Details are on page 25. During tape playback, press to freeze the picture. Press the PAUSE/STILL but- ton repeatedly to advance the picture frame by frame. Details are on page 35.

F.FWD Button

When tape playback is stopped, press to fast forward the tape at high speed. During tape playback, press to fast forward the tape while the picture stays on-screen. Details are on page 35.

Press to add or delete channel numbers. Details are on page 13.

1 2 3

4 5 6

Cassette Compartment

Insert a video cassette tape here.

VCR Display Panel

Information about VCR opera- tions is displayed here.

PLAY

REW F.FWD

STOP

EJECT

POWER Light

This light indicates that the power is on.

VCR/TV Light

This light appears when the VCR is in VCR position.

REC(ord) Light

This light appears during a recording. It flashes when a recording is paused.

TIMER Light

This light glows when you turn off the power to set a timer recording. It also glows during a One-Touch Recording. It flashes when you turn off the power to set a timer recording if a tape has not been placed in the VCR. It flashes when all timer recordings have finished.

CST.IN Light

This light appears when a tape is in the VCR.

Remote Sensor

Receives a signal from your remote control so you can operate your VCR from a distance.

POWER Button

Press to turn the VCR power on and off.

POWER VCR/TV

Front Panel 21

F.FWD (Fast Forward) Button

When tape playback is stopped, press to fast forward the tape at high speed. During tape playback, press to fast for- ward the tape while the picture stays on-screen. Details are on page 35.

PLAY Button

Press to play a tape. Also, press to release Slow, Search, or Still mode and to return to normal playback. Details are on page 35.

STOP/EJECT Button

Press once to stop the tape. When tape play- back is stopped, press to eject the tape.

REW(ind) Button

When tape playback is stopped, press to rewind the tape at high speed. During tape playback, press to rewind the tape while the picture stays on- screen. Details are on page 35.

PLAY

REWF.FWD

STOP

EJECT

VCR/TV Button

Use to select the signal that your TV receives.

???VCR Position

Use to watch a tape, to watch a program while recording it, or to watch a TV broadcast using the CHANNEL o/p or Number buttons. The VCR/TV light will appear when the VCR is in VCR position.

???TV Position

Use to watch TV or to watch one program while recording another. Details are on page 32.

CHANNEL o/p Buttons

Press to scan up or down through the

VCR???s channels.

TRACKING Function

During normal tape playback or slow motion tape playback, press the CHAN- NEL o/p buttons to adjust the track- ing. Details are on page 41.

REC(ord)/OTR Button

Press once to start a recording. Details are on page 24. Press repeatedly to start a One- Touch Recording (an immediate recording, 30 minutes to eight hours long) of the channel you are watching. Details are on page 25.

PAUSE Button

While recording, press to temporarily stop the recording. Press a second time to resume normal recording. Details are on page 24. You can not pause a One-Touch Recording. Details are on page 25. During tape playback, press to freeze the picture. Press repeatedly to advance the still picture frame by frame.

Details are on page 35.

AC Power Cord

Connect to a standard AC outlet to supply power to the VCR.

VIDEO OUT Jack

Connect a cable going to the video in jack of a camcorder, another VCR, or an audio-visual source (laser disc player, video disc player, etc.) here. Details are on pages 10,

VIDEO IN Jack

Connect a cable coming from the video out jack of a cam- corder, another VCR, or an audio-visual source (laser disc player, video disc player, etc.) here. Details are on page 33.

CH3/CH4 Switch

Set to channel 3 or 4 to use your TV with your VCR. Set your TV to the same chan- nel. Details are on page seven.

OUT Jack

Use the supplied RF coax- ial cable to connect this jack to the Antenna In Jack on your TV or Cable Box/DBS. Details are on pages six - nine.

Read and follow the steps below to play a tape.

1

Turn on the TV and set it to channel 3 or 4, whichever channel the CH3/CH4 switch on the back of the VCR is set to.

Playing 23

1Turn on the TV.

2Insert a tape.

2

Insert a tape in the VCR. The POWER and CST.IN lights will appear. If the tape???s record tab has been removed, the VCR/TV light will appear and playback will begin automatically.

3

If playback does not start automatically, press the VCR/TV button to put the VCR in VCR position (the VCR/TV light will appear). Then, press the PLAY button.

4

Press the STOP button to stop playback.

5

Press the REWIND button to rewind the tape.

6

When the tape has finished rewinding, press the EJECT button to remove the tape.

Helpful Hints

???If the tape you want to play is already in the VCR, make sure the VCR power is on and the VCR is in VCR position. (Press the VCR/TV button so that the VCR/TV light appears.) Then, press the PLAY but- ton.

???Other playback options and fea- tures are on pages 34 - 41.

24 Recording

Read and follow the steps below to record a television program.

1

Turn on the TV; set it to channel 3 or 4, whichever the CH3/CH4 switch on the back of the VCR is set to.

2

Insert a tape with its record tab intact (see page five) in the VCR. The POWER, VCR/TV, and CST.IN lights will appear.

3

If the VCR/TV light does not appear, press the VCR/TV button so that the VCR/TV light appears.

4

Press the SPEED button until the desired tape speed appears on-screen. The tape speed will disappear after about five seconds.

You can change the tape speed while the VCR is recording, but some distortion may appear on the tape. Details about tape speed are on page 45.

5

Use the CHANNEL o/p buttons or the Number buttons to select the channel to be recorded.

6

Press the RECORD button once to start recording. The REC(ord) light will appear. If the tape is missing the record tab, the VCR will eject the tape.

7

To pause the recording (for example, during commer- cials), press the PAUSE/STILL button once. The REC(ord) light will flash.

To resume recording, press the RECORD button or the PAUSE/STILL button again. The REC(ord) light will appear.

8

Press the STOP button to stop recording.

1Turn on the TV.

2 Insert a tape.

8

Helpful Hints

???Other recording options are on pages 25 - 33.

???The VCR will record in a preset vol- ume.

???Pause mode will automatically switch to Stop mode after five min- utes to protect the VCR and the tape from damage. When a record- ing is paused, you may review the time remaining with the ??? marks on-screen. Each ??? mark equals one minute remaining. During the last minute of paused recording, the ??? mark will flash.

???If any menu is activated on the TV screen, the RECORD button on the remote control does not function.

Press the COUNTER RESET/EXIT button to remove the menu. Then, press the RECORD button.

The One-Touch Recording function allows you to program an immediate timed recording 30 minutes to eight hours long. Before you begin, make sure:

???Channels are set up.

???The desired recording speed (SP, LP, SLP) has been selected with the SPEED button.

???There is a tape in the VCR. Make sure the tape???s record tab is intact and the tape is long enough to record the program(s).

???The VCR is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

Starting an OTR

1

Use the CHANNEL (o/p) buttons or the Number but- tons to select the channel you want to record.

2

Press the REC(ord)/OTR button on the VCR repeatedly until the desired recording length (30 minutes to eight hours) appears in the upper left corner of the screen.

Recording will begin immediately.

OTR (0:30)

Stopping an OTR

To stop an OTR before recording is finished, press the STOP but- ton on the remote control. To cancel the OTR but continue recording, press the REC(ord)/OTR button on the VCR repeat- edly until REC appears in the upper left corner of the screen.

One-Touch Recording 25

2Press the REC(ord)/OTR button on the VCR repeat- edly.

POWERVCR/TV EJECT

Helpful Hints

???To change the recording length while an OTR is in progress, press the REC(ord)/OTR button on the VCR repeatedly until the desired length appears on-screen.

???You can not pause recording during an OTR.

???If the preset time for a timer recording comes up during an OTR, the OTR has priority. The timer recording will not occur.

???To show the time remaining for an OTR, press the DISPLAY button repeatedly until OTR and the time remaining appear in the upper left corner of the screen.

???If the end of the tape is reached during an OTR, the VCR will stop recording, eject the tape, and turn itself off.

26 Timer Recording

Follow the steps below to program your VCR to record TV pro- grams while you???re away from home. You can program up to seven timer recordings. For each one, the VCR will turn itself on, record, and turn itself off automatically. Before you begin make sure:

???Channels are set up.

???The clock is set.

???There is a tape in the VCR. Make sure the tape???s record tab is intact and the tape is long enough to record the program(s).

???The VCR is on and in VCR position. The VCR/TV light will appear. If it does not, press the VCR/TV button once. (When you finish programming the timer recording, you must turn off the VCR.)

1

Press the MENU button until the TIMER PROGRAM- MING menu appears. Program numbers that do not have a timer recording stored will flash.

TIMER PROGRAMMING

PROG. 1 2 3 4 5 6 7

DATE

START TIME

END TIME

CHANNEL

REC SPEED

2

Press the PLAY button or the STOP button repeatedly to select a program number. Then, press the F.FWD button.

(If you select a program number that already has a timer recording stored, information about that program will appear. Press the PLAY button or the STOP button to select another program num- ber.)

3

Press the PLAY button or the STOP button repeatedly to select a ONCE, DAILY, or WEEKLY recording. When the arrow is beside your choice, press the F.FWD button.

???ONCE - The VCR will record a TV program on any day you choose, up to 12 months away.

???DAILY - The VCR will record a TV program at the same time on the same channel every day, Monday through Sunday.

???WEEKLY - The VCR will record a TV program at the same time on the same channel every week, for example, every Monday.

PROGRAM NUMBER 1

???ONCE

DAILY

WEEKLY

POWERVCR/TV EJECT

2-3

Press the PLAY button or the STOP button repeatedly until the desired month appears. Then, press the F.FWD button.

Next, press the PLAY button or the STOP button repeat- edly until the desired day appears. Then, press the F.FWD button.

The day of the week will appear automatically. You can not pro- gram the VCR to record more than one year in advance.

5

Enter the recording???s start time.

Press the PLAY button or the STOP button repeatedly until the desired hour appears. Press the F.FWD button. Press the PLAY button or the STOP button repeatedly until the desired minute appears. Press the F.FWD but- ton.

Finally, press the PLAY button or the STOP button to point to AM or PM. AM or PM will flash beside the time. Press the F.FWD button.

6

Repeat the procedure in step 5 to set the recording???s end time.

POWERVCR/TV EJECT

4-6

8

Press the PLAY button or the STOP button repeatedly to select a tape speed. The arrow will appear beside your choice. The selected tape speed will flash beside REC SPEED.

SLP

9

8

7

9

Press the COUNTER RESET/EXIT button.

10

Press the POWER button to turn off the VCR. The TIMER light will appear. (The TIMER light will flash if there is not a tape in the VCR.)

If a timer recording will take place several hours or days from now, you may use the VCR until time for the timer recording. Just make sure you turn off the VCR about five minutes before the scheduled start time.

The VCR must be off for a timer recording to take place! Make sure a tape is in the VCR.

Helpful Hints

???The TIMER PROGRAMMING menu will not appear at step 1 if the clock is not set. Follow the steps on pages 14 - 15 to set the clock.

???Enter the information while the space is flashing.

???Press the REWIND button to go back one step from the current step during steps 2-8.

???To stop a started timer recording, press the STOP/EJECT button on the VCR.

More Helpful Hints are on page 46.

Cancelling a Timer Recording

1

Press the MENU button so that the TIMER PROGRAM- MING menu appears.

To cancel a timer recording

1 2 3

2

Press the PLAY button or the STOP button until the pro- gram number you want to cancel appears on-screen.

4 5 6

SPEED 0 +100

3

While the program number is flashing, press the REWIND button to cancel the timer recording.

4

Press the COUNTER RESET/EXIT button to exit.

Correcting a Timer Recording

If you need to correct a timer recording after you have finished setting the program, follow these steps. Make sure the VCR is on and is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

1

3

2

1

Press the MENU button so that the TIMER PROGRAM- MING menu appears.

2

Press the PLAY button or the STOP button until the timer recording you want to correct appears on-screen.

3

Select the information you want to change using the F.FWD button. Press the REWIND button to go back one step. (There is an exception. Do not press the REWIND button while the program number is flashing. If you do, you will cancel the timer recording completely.)

4

While the information is flashing, enter the correct infor- mation by pressing the PLAY button or the STOP button.

5

When all the information is correct, press the COUNTER RESET/EXIT button to exit. Turn off the VCR before the timer recording.

To correct a timer recording

POWERVCR/TV EJECT

2&4

30 Auto Return

Follow the steps below to make the VCR rewind to the beginning of the programs after it has finished all timer recordings. Make sure:

???The VCR is on and is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

1

Press the MENU button repeatedly until the VCR SET UP menu appears.

VCR SET UP

???SATELLITE LINK

AUTO REPEAT

RENTAL

AUTO RETURN

AUDIO OUT

TV STEREO [ON]

SAP

2

Press the PLAY button or the STOP button repeatedly to select AUTO RETURN.

VCR SET UP

3

Press the F.FWD button so that [AUTO] appears next to AUTO RETURN on-screen.

4

Press the COUNTER RESET/EXIT button to exit.

Remember to turn off the VCR before the timer recording. When all the timer recordings are completed, the TIMER light will flash and the VCR will rewind the tape to the beginning of the record- ed programs.

POWERVCR/TV EJECT

2

Helpful Hints

???If additional timer recordings are programmed to take place later, the Auto Return function will not operate until all the programs are recorded.

???To cancel this function, follow steps 1 - 2 above. At step 3, press the F.FWD button so that [AUTO] no longer appears beside AUTO RETURN. Press the COUNTER RESET/EXIT button to exit.

If you connect your VCR to a satellite tuner that has the Electronic Program Guide, the VCR will turn itself on, record, then turn itself off. First, read the owner???s manual of your satellite tuner; then, follow these steps to set up your VCR. Before you begin:

???Use audio and video cables to connect the AUDIO/VIDEO IN jacks on the back of the VCR to the AUDIO/VIDEO OUT jacks on the satellite tuner.

???Press the SPEED button to select the desired tape speed (SP, LP, or SLP).

1

Set the program to be recorded on the satellite tuner. See your satellite tuner owner???s manual for details.

2

Press the MENU button repeatedly until the VCR SET UP menu appears.

VCR SET UP

???SATELLITE LINK

AUTO REPEAT

RENTAL

AUTO RETURN

AUDIO OUT

TV STEREO [ON]

SAP

3

Press the PLAY button or the STOP button repeatedly to select SATELLITE LINK.

4

Press the F.FWD button so that [ON] appears beside SATELLITE LINK. After one second, the VCR will turn itself off and the TIMER light will appear on the VCR display panel.

Set the program to 1 be recorded on the

satellite tuner.

POWERVCR/TV EJECT

Helpful Hints

???To exit a stand-by mode of the Auto Satellite Link, press the POWER button to turn on the VCR. The VCR sets SATELLITE LINK to OFF automatically.

???To stop an Auto Satellite Link recording that is in progress, press the STOP/EJECT button on the VCR.

???If the preset time for an Auto Satellite Link comes up during a timer recording, the timer recording has priority.

???If a program has copy guard pro- tection, it may not record clearly.

???If noise appears on the TV screen when you view a program, connect the satellite tuner directly to the TV.

???When you use this feature, the first few seconds of a program may not be recorded.

???If your satellite tuner has the syn- chronized timer feature by the broadcasting time of a program, refer to the tuner???s owner???s manual.

1

Press the RECORD button to start a recording. Details are on page 24.

2

Press the VCR/TV button to put the VCR in TV position.

The VCR/TV light will disappear.

3

4

Select the channel you want to watch at the TV.

Set the TV to channel 3 or 4.

6

To stop recording, press the STOP button.

2

5

6

VCR 2 - Recording VCR

2. Video cable from VIDEO OUT Jack of VCR 1 to VIDEO IN Jack of VCR 2

1

VCR 1 will play your tape. Insert a prerecorded tape in VCR 1. If the tape does not have a record tab, playback begins. If this happens, press the STOP/EJECT button on VCR 1 once.

2

VCR 2 will record your tape. Insert a blank tape in VCR 2.

Make sure the record tab is intact (details are on page five). Make sure the VCR 2 power is on and VCR 2 is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

3

Turn on the TV and set it to channel 3 or 4, whichever channel the CH3/CH4 switch on VCR 2 is set to.

4

Point the remote control at VCR 2. Press the Number buttons 0, 0. AUX will appear on-screen.

3. RF coaxial cable from VCR???s OUT Jack to TV???s

ANTENNA IN

Jack

5

Point the remote control at VCR 2. Use the SPEED but- ton to select SP, LP, or SLP.

6

Press the PLAY button on VCR 1 and the REC(ord)/OTR button on VCR 2 at the same time.

7

To stop recording, press the STOP/EJECT button on VCR 2 once, then stop the tape on VCR 1.

Helpful Hints

???Unauthorized recording of copy- righted television programs, video tapes, or other materials may infringe on the rights of copyright owners and violate copyright laws.

???Audio and video cables are not sup- plied.

???The illustration uses two VCRs just like yours. Different VCRs may oper- ate differently.

34 Repeat Play

Follow the steps below to program the VCR to play a tape over and over. Make sure:

???The VCR is on and is in VCR position. The VCR/TV light will appear on the front panel. If it does not, press the VCR/TV but- ton once.

???There is a tape in the VCR.

1

Press the MENU button repeatedly until the VCR SET UP menu appears.

VCR SET UP

???SATELLITE LINK

AUTO REPEAT

RENTAL

AUTO RETURN

AUDIO OUT

TV STEREO [ON]

SAP

2

Press the PLAY button or the STOP button repeatedly to select AUTO REPEAT.

VCR SET UP

SATELLITE LINK

???AUTO REPEAT

RENTAL

AUTO RETURN

AUDIO OUT

TV STEREO [ON]

SAP

3

Press the F.FWD button so that [ON] appears next to AUTO REPEAT on-screen. Tape playback will begin immedi- ately. AUTO REPEAT B will appear on-screen briefly.

(If you are fast forwarding or rewinding the tape, you must first press the COUNTER RESET/EXIT button to exit, then press the PLAY button to begin tape playback.)

The VCR will play the tape to the end, rewind it, then play it again. (TV programming will appear on-screen while the tape is rewinding.)

POWERVCR/TV EJECT

2

Helpful Hints

???To cancel AUTO REPEAT, follow steps 1 - 2 above. At step 3, press the F.FWD button so that [ON] no longer appears beside AUTO REPEAT. Press the COUNTER RESET/EXIT button to exit.

???The COUNTER MEMORY button does not function if AUTO REPEAT is set to [ON].

???The real-time counter memory is cancelled if AUTO REPEAT is set to

[ON].

Super High Speed Searching (LP/SLP)

1

During tape playback, press the F.FWD button or the REWIND button, then press again. The VCR will now search

in super high speed.

2

To return to playback, press the PLAY button.

Viewing a Still Picture

1

During tape playback, press the PAUSE/STILL button. A still picture will appear on-screen.

NOTE: You can advance the still picture frame by frame by pressing the PAUSE/STILL button repeatedly.

2

To release the still picture and return to normal playback, press the PLAY button.

Viewing a Slow Motion Picture

1

During tape playback, press the SLOW button. The tape will play in slow motion.

NOTE: You can control the speed of slow motion playback by pressing the F.FWD button (faster) or the REWIND button (slower).

2

To release Slow mode and return to normal playback, press the PLAY button.

Helpful Hints

???Slow and Still modes will automati- cally switch to Stop mode after five minutes to protect the VCR and the tape from damage.

???SP/LP/SLP means this feature will work with tapes recorded in Standard Play, Long Play, or Super Long Play.

???LP/SLP means this feature will work with tapes recorded in Long Play or Super Long Play. For details about tape speed, see page 45.

Follow the steps below to reset the real-time counter to zero at a tape location you want to refer to later. Make sure:

???The VCR is on and is in VCR position. The VCR/TV light will appear. If it does not, press the VCR/TV button once.

???There is a tape in the VCR.

1

Play, fast forward, or rewind a tape to the location that you would like to refer to later. Press the STOP button to stop the tape.

2

Press the COUNTER RESET/EXIT button to reset the real-time counter to zero.

0 : 00 : 00

3

Press the COUNTER MEMORY button so that M appears on-screen beside the real-time counter.

M 0 : 00 : 00

4

To go to a tape location where the real-time counter was reset to zero, press the REWIND button or the F.FWD button when playback is stopped.

When the tape reaches the point at which the real-time counter was reset to zero, the tape will stop.

Press the PLAY button to watch the tape.

POWERVCR/TV EJECT

1

Helpful Hints

???You may only set the real-time counter memory at one location at a time. If you set the real-time counter to zero at a second loca- tion, the previous real-time counter to zero setting will be erased.

???To erase the real-time counter memory, press the COUNTER MEMORY button repeatedly so that the M disappears from the screen.

???The COUNTER MEMORY button does not function if AUTO REPEAT is set to [ON].

38 Index Search

When you make a recording, the VCR places an index mark at the beginning of the recording. Essentially, an index mark is a type of ???bookmark??? for your tape. This feature is useful if you have sever- al different programs recorded on a single tape.

You may skip over programs by following the steps below. Before you begin, make sure:

???The VCR is on and is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

???There is a tape in the VCR.

1

Press the MENU button repeatedly until the SEARCH SELECT menu appears.

SEARCH SELECT

???QUICK-FIND

INDEX SEARCH

TIME SEARCH

2

Press the PLAY button or the STOP button repeatedly to select INDEX SEARCH. Then, press the F.FWD button.

3

Within 30 seconds, press the PLAY button or the STOP button repeatedly until the number of programs that you want to skip appears beneath INDEX SEARCH on-screen.

(Example: 03 for three programs)

1

4

3

POWERVCR/TV EJECT

2

4

While the number of programs is flashing, press the REWIND button or the F.FWD button.

The VCR begins rewinding or fast forwarding to the beginning of the desired program. When the program is reached, the VCR will start playback automatically.

Helpful Hints

???You may also activate the Index Search by pressing the INDEX SEARCH button. Then, continue from step 3.

???Every time an index mark is passed, the number of programs beneath INDEX SEARCH on-screen decreas- es by one.

???Up to 20 index marks may be stored and searched.

???This function is not available during recording.

???Press the STOP button to stop the search.

???To exit Index Search mode, press the COUNTER RESET/EXIT button.

???The time gap between index marks should be greater than 1 minute for SP recording, 2 minutes for LP recording, and 3 minutes for SLP recording.

The Time Search function allows you to go to a specific point on a tape. You will enter the exact amount of playback time that you wish to skip in order to reach the specified point.

Make sure:

???The VCR is on and is in VCR position. (The VCR/TV light will appear. If it does not, press the VCR/TV button once.)

???There is a tape in the VCR.

1

Press the MENU button repeatedly until the SEARCH SELECT menu appears.

SEARCH SELECT

???QUICK-FIND

INDEX SEARCH

TIME SEARCH

2

Press the PLAY button or the STOP button repeatedly to select TIME SEARCH. Then, press the F.FWD button.

TIME SEARCH

- : - -

3

Within 30 seconds, press the PLAY button or the STOP button repeatedly until your desired length of time appears. (Example: 2:50 for 2 hours 50 minutes) You may also press and hold the PLAY button or the STOP button until you reach the desired length of time.

4

Within 30 seconds, press the REWIND button or the F.FWD button. The VCR begins rewinding or fast forwarding to the specified point. The time counts down on-screen beneath TIME SEARCH as the searching progresses. When 0:00 appears beneath TIME SEARCH, the VCR will start playback automatically.

Time Search 39

POWERVCR/TV EJECT

32

Helpful Hints

???You may also activate the Time Search by pressing the TIME SEARCH button. Then, continue from step 3.

???You can set a Time Search for up to 9 hours, 59 minutes (9:59).

???Time Search is not available during recording.

???To exit Time Search mode, press the COUNTER RESET/EXIT button.

???To cancel a Time Search already in progress, press the STOP button.

40 Quick Find

The Quick Find feature locates the beginning of each recording on a tape, then plays the first portion of the recording at high speed for 30 seconds. After it plays the portion, the VCR fast forwards the tape to the next recording. This process is repeated until the end of the tape is reached, or until you stop the Quick Find.

To start a Quick Find, press the QUICK-FIND button on the remote control, or follow the steps below.

1

Press the MENU button repeatedly until the SEARCH SELECT menu appears.

SEARCH SELECT

???QUICK-FIND

INDEX SEARCH

TIME SEARCH

2

Press the PLAY button or the STOP button repeatedly to select QUICK-FIND, then press the F.FWD button. The VCR will fast forward the tape to the beginning of the next recording. The VCR will play the tape at high speed for 30 sec- onds, then go to the next recording.

To skip immediately to the beginning of the next recording on the tape, press the QUICK-FIND button on the remote control.

3

To resume normal tape playback, press the PLAY button.

POWERVCR/TV EJECT

Helpful Hints

???There must be a tape in the VCR.

???This function will not operate during a recording.

???To cancel a Quick Find that is in progress, press the STOP button.

???When the end of a tape is reached during a Quick Find, the VCR will rewind the tape to the beginning, eject the tape, and turn itself off. If a real-time counter memory is set, the VCR will rewind the tape to the point at which the real-time counter was set to zero, then stop.

The indication SAP or STEREO that appears on this side of the status display tells you if the program you???re watching is available in second audio or stereo. Even though a program is available in second audio or stereo, you still must program the VCR to receive or record the program. Follow the directions on page 43. This indication is not available during tape playback.

OR

OR, for monaural sound, connect only the RF coaxial cable (supplied) to the VCR???s OUT Jack and to the TV???s ANTENNA IN Jack.

1

Press the MENU button repeatedly until the VCR SET UP menu appears.

VCR SET UP

???SATELLITE LINK

AUTO REPEAT

RENTAL

AUTO RETURN

AUDIO OUT

TV STEREO [ON]

SAP

2

Press the PLAY button or the STOP button repeatedly to select TV STEREO or SAP. Press the F.FWD button, then [ON] will appear to the right of your selection.

VCR SET UP

SATELLITE LINK

AUTO REPEAT

RENTAL

POWERVCR/TV EJECT

1 2 3

AUTO RETURN

AUDIO OUT

??? TV STEREO [ON]

SAP

3

Press the COUNTER RESET/EXIT button to exit.

4

To play a tape, press the PLAY button. Or, to record, select the channel to be recorded using the CHANNEL (Up/Down) buttons, then go to step 5.

5

5

2

Press the RECORD button to start recording.

Helpful Hints

???You can only receive and record in stereo or second audio programs that are broadcast in second audio or stereo. You can only play in stereo or second audio tapes that were recorded in stereo or second audio. Please see page 42 to deter- mine if the program you want to watch/record is being broadcast in stereo or second audio.

???If you select second audio when second audio is not available, the VCR will record normal audio.

90 Days Free Labor/One Year Parts Exchange.

WHO IS COVERED?

You must have proof of purchase to receive war- ranty service. A sales receipt or other document showing that you purchased the product is consid- ered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product. For 90 days thereafter, all parts will be repaired or replaced, and labor is free. From 90 days to one year from the day of purchase, all parts will be repaired or replaced, but you pay for all labor charges. After one year from the day of purchase, you pay for the replacement or repair of all parts, and for all labor charges.

All parts, including repaired and replaced parts, are covered only for the original warranty period. When the warranty on the product expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

???labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna sys- tems outside of the product.

???product repair and/or part replacement because of misuse, accident, unauthorized repair or other cause not within the control of Philips Consumer Electronics Company.

???reception problems caused by signal conditions or cable or antenna systems outside the unit.

???a product that requires modification or adapta- tion to enable it to operate in any country other than the country for which it was designed, man- ufactured, approved and/or authorized, or repair of products damaged by these modifications.

???incidental or consequential damages resulting from the product. (Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you. This includes, but is not limited to, prerecorded material, whether copyrighted or not copyright- ed.)

???damage caused by the use of non-VHS tapes or tapes that have not been tested and labeled for use in two, four, six, and eight hour VHS recorders.

???a product that is used for commercial or institu- tional purposes (including but not limited to rental purposes).

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics Company. In countries where Philips Consumer Electronics Company does not distribute the product, the local Philips service

This product must be carried in for repair.

organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of purchase. Attach it to this owner???s manual and keep both nearby. Also keep the origi- nal box and packing material in case you need to return your product.

BEFORE REQUESTING SERVICE...

Please check your owner???s manual before request- ing service. Adjustments of the controls discussed there may save you a service call.

TO GET WARRANTY SERVICE IN U.S.A.,

PUERTO RICO OR U.S. VIRGIN ISLANDS...

Take the product to a Philips factory service center (see enclosed list) or authorized service center for repair. When the product has been repaired, you must pick up the unit at the center. Centers may keep defective parts.

(In U.S.A., Puerto Rico and U.S. Virgin Islands, all implied warranties, including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this express warranty. Because some states do not allow limitations on how long an implied warranty may last, this limitation may not apply to you.)

TO GET WARRANTY SERVICE IN CANADA...

Please contact Philips at:

1-800-661-6162 (French Speaking)

1-800-363-7278 (English Speaking)

(In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of mer- chantability or fitness for a particular purpose. Philips is not liable under any circumstances for any direct, indirect, special, incidental, or consequential damages, howsoever incurred, even if notified of the possibility of such damages.)

REMEMBER...

Please record below the model and serial numbers found on the product. Also, please fill out and mail your warranty registration card promptly. It will be easier for us to notify you if necessary.

MODEL # ________________________________

SERIAL # ________________________________

This warranty gives you specific legal rights. You may have other rights which vary from state to state.

SUPPLIED ACCESSORIES

Check to be sure the items on this page are packed with your VCR. These accessories are provided to help you use or set up your VCR.

Two ???AA??? Batteries 4835 138 17012

RF Coaxial Cable, 75 ohm 4835 323 27011

If any of these items are not included, or if you need to replace an item, contact our Service Solutions Group at the address below.

Service Solutions Group

P.O. Box 967

Greeneville, TN 37744-0967

Or, call 1-800-851-8885.
