know your Kenwood deep fryer

safety

???Never plug in the fryer before filling the bowl with oil.

???Keep children away during use and after - fat stays hot for a long time.

???Never let the cord touch hot surfaces or hang down over the worktop edge - a child could grab it and pull the fryer down. Place excess cord in cord storage area at the back of the fryer.

???Never touch the bowl, pour away oil or move your fryer while the oil???s hot.

???Never put the electrics unit in water. Remove it before washing the rest of your fryer.

???After cleaning, ensure the bowl and its electric pins are dry before use.

???Never leave your fryer on unattended.

???Take care when removing the electrics unit - the temperature probes may be hot.

???Do not use if there is any damage to the fryer, cord or plug. Get it checked or repaired: see ???service???.

???Only use the electrics unit supplied.

???Watch out for steam during cooking and when you open the lid.

???Never put your fryer near or on cooker hot plates.

???Always unplug the fryer after use.

???This appliance is not intended to be operated by means of an external timer or separate remote-control system.

???This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

???Children should be supervised to ensure that they do not play with the appliance.

???Only use the appliance for its intended domestic use. Kenwood will not accept any liability if the appliance is subject to improper use, or failure to comply with these instructions.

before plugging in

???Make sure your electricity supply is the same as the one shown on the underside of the electrics unit.

Important ??? UK only

???The wires in the cord are coloured as follows: Green and Yellow = Earth,

Blue = Neutral, Brown = Live.

???The appliance must be protected by a 13A approved (BS1362) fuse.

???WARNING: THIS APPLIANCE MUST BE

EARTHED.

Note:

???For non-rewireable plugs the fuse cover MUST be refitted when replacing the fuse. If the fuse cover is lost then the plug must not be used until a replacement can be obtained. The correct fuse cover is identified by colour and a replacement may be obtained from your Kenwood Authorised Repairer (see Service).

???If a non-rewireable plug is cut off it must be DESTROYED IMMEDIATELY.An electric shock hazard may arise if an unwanted non-rewireable pug is inadvertently inserted into a 13A socket outlet.

???This appliance conforms to EC directive 2004/108/EC on Electromagnetic Compatibility and EC regulation no. 1935/2004 of 27/10/2004 on materials intended for contact with food.

before using for the first time

1Remove all packaging.

2Dismantle: see ???to dismantle, assemble and use your fryer???.

3Wash the parts: see ???cleaning???.

know your Kenwood fryer

???removable lid with permanent mesh filter

???viewing window

???lid seal

???condensation trap

???rise and fall control

???pouring lips

???removable bowl

???lid release

???carrying handles

???electrics unit

???timer

???temperature control with neon light

???temperature probes

???cord storage

to dismantle, assemble and use your fryer

to dismantle

1Push the lid release ??? down to open the lid. Then lift the lid off.

2Lift up the handle and remove the basket.

3Pull out the electrics unit and then remove the bowl.

???Before removing the electrics unit check that the cord is released from the cord storage area at the back of the fryer .

to assemble and use

1Insert the bowl ??? ???MAX??? and ???MIN??? marks to the back of the fryer.

2Then insert the electrics unit ??? ??? cord to the back of the fryer + .

3Pour in the oil. The level must be between the ???MAX??? and ???MIN??? marks .

4Insert the basket and close the lid. Then lower the handle by sliding back the rise & fall control ???.

5Plug in and select the required temperature ???.

6The light goes out when the oil reaches the right temperature to start frying. Fill the basket and lower into the oil . Don???t exceed the maximum food quantities stated. The light will come on and off as the fryer maintains the temperature.

7Set the timer ??? by pressing the button until the required time is reached. The time will start counting down as soon as the button is released. See ???operating the timer???.

8When ready, raise the basket and allow the food to drain before opening the lid.

???To re-use oil, allow to cool then pour the oil through fine muslin or absorbent paper.

???Always unplug the fryer after use. hints

???We would recommend the use of a good quality oil for deep frying, such as corn oil or groundnut oil. A good quality solid fat may also be used. Other oils may be used if they are specifically recommended by the manufacturer for deep frying. Never mix different oils or fat and do not use olive oil, butter or margarine as they will smoke or bubble over.

???Pre-cooked food needs a higher temperature than raw food.

???Cook food thoroughly. The outside may look ready before the inside is cooked.

???Keep your fryer with oil (cooled and strained) inside it, ready for use. The lid keeps the dust out.

???Before frying battered food, drain off excess batter.

???Tomake chips, cut potatoes up evenly, so they cook evenly. Rinse and dry before frying. For best results use dry floury textured potatoes i.e. King Edwards or Maris Piper.

???To prolong the life of your fryer, filter the oil after each use and change it after 8 - 10 uses.

???Shake off any excess ice before frying frozen foods. maximum food capacities

???fresh chips 1.2Kg

???frozen chips 1Kg oil capacity

???maximum oil 2.5 litres

???minimum oil 2 litres

operating the timer

1Press the button once, the display will flash ???00???.

2Press again to set the countdown time in 1 minute intervals. Hold the button in until the required set time is reached ie ???05??? = 5 minutes. Then release the button.

Note: The timer will only display seconds when the countdown time is below 1 minute.

3The display will flash for 5 seconds - during this period the set time can be increased by holding the button in again. After 5 seconds the display will stop flashing and the countdown will begin.

4To change the countdown time during operation, press and hold the button in for 3 seconds. The display will reset to ???00??? and a new time can be set.

5When the countdown has finished the timer will ???beep??? for 15 seconds. To stop the timer beeping, press the button once.

6The display will automatically turn off after 45 seconds if not in use.

care and cleaning

???Never start cleaning until the oil has cooled down.

???Always unplug and remove the electrics unit before cleaning.

???Ensure everything???s completely dry before reassembling.

electrics unit

???Never put it in water.

???Before removing the electrics unit check that the cord is released from the cord storage area at the back of the fryer .

???Pull out. Wipe with a damp cloth and dry thoroughly. lid

???Remove and soak in hot soapy water for 20 minutes. basket

???After each use, remove and soak in hot soapy water for 20 minutes. Then use a stiff brush.

fryer body and bowl

???Soak in hot soapy water for 20 minutes. Then use a non-abrasive cleaner.

???If you have a dishwasher everything - except the electrics unit - is dishwasher safe. Your dishwasher may darken the inside of the lid but it will still work perfectly. For baked on oil, we recommend soaking the bowl prior to dishwashing.

replacing the timer battery

1Turn the battery cover anti-clockwise and remove the battery .

2Replace the battery - type L1154 or equivalent from your local electrical retailer or chemist.

3Fit the new battery ensuring it is the correct way round and replace the cover.

guarantee (UK only)

If your fryer goes wrong within one year from the date you bought it, we will repair or where necessary replace it free of charge provided:

???you have not misused, neglected or damaged it;

???it has not been modified (unless by Kenwood);

???it is not second-hand;

???it has not been used commercially;

???you have not fitted a plug incorrectly; and

???you supply your receipt to show when you bought it.

This guarantee does not affect your statutory rights.

service and customer care

???If the cord is damaged it must, for safety reasons, be replaced by Kenwood or an authorised Kenwood repairer.

???If you experience any problems with the operation of the fryer, before calling for assistance refer to the troubleshooting guide.

UK

If you need help with:

???using your fryer or

???servicing or repairs (in or out of guarantee)

???call Kenwood on 023 92392333 and ask for Customer Care. Have your model number ready

- it???s on the underside of the fryer.

spares and attachments

???call 0870 2413653 other countries

???Contact the shop where you bought your fryer.

???Designed and engineered by Kenwood in the UK.

???Made in China.

IMPORTANT INFORMATION FOR CORRECT

DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as urban waste.

It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.
