HIGHLIGHTS

Productivity, ???exibility and scalability at a great price

INFOPRINT 1532 EXPRESS, INFOPRINT 1552, INFOPRINT 1572 AND THE

M40 MFP OPTION

Compete more effectively in today???s demanding business environment with affordable and reliable printing solutions. As general office printing needs change and grow, InfoPrint Solutions Company responds with printers

designed to deliver higher throughput, faster speeds and improved print quality, while keeping total cost of ownership (TCO) low.

The InfoPrint 1532 Express is ideal for small and medium businesses (SMBs). The InfoPrint 1552 and InfoPrint 1572 are

designed for medium and large workgroups. These printers offer a range of print speeds, ???exible connectivity and extensive input and output options to enable scalable solutions with low costs and high productivity. With

the addition of an M40 MFP Option, the InfoPrint 1552n and 1572n can support users with advanced copy, fax, scan and send capabilities.

INCREASE PRODUCTIVITY AND

PERFORMANCE ON THE NETWORK

The InfoPrint 1532 Express, the InfoPrint 1552 and the InfoPrint 1572 can help you meet deadlines with output delivery of up to 35,

45 and 50 letter (33, 43 and 47 A4) pages per minute (ppm),1 respectively and standard and optional ???nishing options.

The exceptionally easy-to-use operator panel offers bold icons, an all-points addressable display, ???show me??? graphics and text, and ???tell me more??? selections. To print PDF documents securely and quickly at the printer, use the USB direct port and a USB ???ash memory device.

With standard ImageQuick function, you can store forms or critical documents on a Web site or central server and print them on demand, without using a driver. With MarkVision printer management utilities, you can achieve a cross platform printer management solution.

scanner, e-mail print con???rmation, customisable icons and embedded solutions such as scan to folder. Additional functions help to produce professional results: reduce and enlarge, separator sheets, margin shift, edge erase and

MAXIMISE FLEXIBILITY WITH

WIRELESS PRINTING

With the optional 802.11 wireless card, you can adapt easily to existing infrastructures and place printers at the point of need without waiting for IT to recon???gure or install new cables. You can also help reduce installation costs by avoiding the expense of new Ethernet cabling.

ENHANCE SECURITY

Standard and optional features of the InfoPrint 1532 Express, InfoPrint 1552 and InfoPrint 1572 can enhance device and document security. Administrators can con???gure and manage devices by using authenticated and encrypted network communications. PIN-based printing can help increase con???dentiality on individual jobs. Encryption and decryption enable

UPGRADE YOUR INFOPRINT 1552N

OR INFOPRINT 1572N WITH AN

M40 MFP OPTION

It???s easy to turn your InfoPrint 1552n and 1572n single-function printers into a high- performance departmental monochrome print, copy, fax and scan device. Add an M40 MFP Option and you can lower

total cost of printing and provide the functionality required by an On Demand Business.

You can also simplify use. The M40 MFP Option provides job interrupt to accommodate priority copies, USB ???ash memory device print and scan, intuitive job cancel, auto sensing for letter and legal sizes, copy countdown, a legal-size ???atbed

date/time stamping.

The M40 MFP Option includes a hard drive that helps to process jobs faster and provides additional functionality. Scan preview gives users the opportunity to verify that the document is scanned appropriately. Custom job and job build features permit you to combine multiple scanning jobs into a single job.

ENGAGE THE PRINTING EXPERTS

With InfoPrint Solutions Company, you can receive support when you need it from experts with comprehensive knowledge of printers, software and supplies. Same day and next day service offerings are available for all InfoPrint printers. Contact your local InfoPrint Solutions Company representative for availability.

M40 MFP Option

Up to 45 ppm (letter), 43 ppm (A4) Up to 50 ppm (letter), 47 ppm (A4)

For expanded speci???cations, visit: infoprint.com/workgroup

M40 MFP OPTION AT A GLANCE

When the M40 MFP Option is attached to the InfoPrint 1552n printer or InfoPrint 1572n printer, the network printer speci???cations for that particular

printer will apply. For example, the maximum speed of the InfoPrint 1552n printer with the M40 MFP option installed will be up to 45 ppm letter

(43 A4); the maximum speed of the InfoPrint 1572n printer with the M40 MFP Option installed will be 50 ppm letter (47 A4). Please see the speci???c

printer data sheet speci???cations.

M40 MFP OPTION AT A GLANCE

When the M40 MFP Option is attached to the InfoPrint 1552n printer or InfoPrint 1572n printer, the network printer speci???cations for that particular printer will apply. For example, the maximum speed of the InfoPrint 1552n printer with the M40 MFP option installed will be up to 45 ppm letter (43 A4); the maximum speed of the InfoPrint 1572n printer with the M40 MFP Option installed will be 50 ppm letter (47 A4). Please see the speci???c printer data sheet speci???cations.

M40 MFP OPTION AT A GLANCE

When the M40 MFP Option is attached to the InfoPrint 1552n printer or InfoPrint 1572n printer, the network printer speci???cations for that particular printer will apply. For example, the maximum speed of the InfoPrint 1552n printer with the M40 MFP option installed will be up to 45 ppm letter (43 A4); the maximum speed of the InfoPrint 1572n printer with the M40 MFP Option installed will be 50 ppm letter (47 A4). Please see the speci???c printer data sheet speci???cations.

Note: Printer memory options, ???ash memory, applications solution cards such as IPDS feature, Barcode fonts, or decryption cards, may not be compatible with the M40 MFP Option. Please consult your InfoPrint Solutions Company representative.

Note: If ???nishing options are added to the InfoPrint 1552n or 1572n printer, the M40 MFP Option will be placed to the side of the printer.

M40 MFP OPTION SUPPLIES

When installed with an InfoPrint 1552n or InfoPrint 1572n Printer (network models only), InfoPrint 1552 and 1572 toner cartridges are also compatible.

*These numbers re???ect an approximate average yield that has been established for each supply item indicated based on ???ve percent coverage. These yields are not a guarantee of minimum life and are not covered under warranty, but are provided to assist in supplies planning. Actual usage should be used to establish the life of the supply product in each end user???s speci???c application. Many factors, such as print coverage per page, paper type and size, model type and environmental conditions can affect supply life. Declared value in accordance with IS0/IEC 19752.

**All maintenance supplies except the fuser and fuser contained within the maintenance kits are customer installable. Installation support is provided with an InfoPrint Solutions Company maintenance contract. If you do not have an InfoPrint Solutions Company maintenance contract, installation services for these kits are available at InfoPrint Solutions Company current billable service rate for this product, with a one-hour minimum. The maintenance kit must be purchased separately by the customer before contacting InfoPrint Solutions Company for installation.

FOR MORE INFORMATION

To learn more about the InfoPrint

1532 Express, the InfoPrint 1552 and the InfoPrint 1572, visit:

infoprint.com/workgroup

InfoPrint Solutions Company

PO Box 41

North Harbour

Portsmouth

Hampshire PO6 3AU

Basingstoke

United Kingdom

The InfoPrint Solutions Company home page can be found infoprint.com

InfoPrint Solutions Company is a trade name of InfoPrint Solutions Company, LLC, in the United States, other countries or both. InfoPrint Solutions Company, LLC is a joint venture of Ricoh Co., Ltd. and International Business Machines Corporation.

InfoPrint, Intelligent Printer Data Stream and IPDS are trademarks of InfoPrint Solutions Company in the United States, other countries, or both.

IBM and AIX are trademarks of International Business Machines Corporation in the United States, other countries, or both.

Adobe, PostScript and PostScript 3 are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Other company, product and service names may be trademarks or service marks of others.

Windows and Windows Server are trademarks or registered trademarks of Microsoft Corporation in the United States, other countries or both.

Other company, product and service names may be trademarks, or service marks of others.

1Exact speed varies depending on document complexity, system con???guration, software application, driver and printer state.

2InfoPrint Solutions Company does not recommend printing this monthly maximum on a consistent basis.

3Printer stands are available for improved stability.

4Assumes ???ve percent coverage per page. Yields are provided for planning purposes and are not a guarantee of minimum life; actual yields may vary. Declared yield value in accordance with ISO/IEC 19752.

5All maintenance supplies except the fuser and fuser contained within the maintenance kits are customer installable. Installation support is provided in the U.S. Outside the U.S. installation services for these kits are available at InfoPrint Solutions Company current billable service rate for this product, with a one-hour minimum. The maintenance kit must be purchased separately by the customer before contacting InfoPrint Solutions Company for installation.

References in this publication to InfoPrint Solutions Company products, programs or services do not imply that InfoPrint Solutions Company intends to make these available in all countries in which InfoPrint Solutions Company operates. InfoPrint Solutions Company hardware products are manufactured from new parts, or new and used parts. In some cases, the hardware product may not be new and may have been previously installed. Regardless, InfoPrint Solutions Company warranty terms apply.

??Copyright InfoPrint Solutions Company 2007 All Rights Reserved.

IPD03006-GBEN-00

07-IPSTG-000452 (05/07) AD
