IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock, or to prevent property damage, personal injury, or loss of life.

WARNING ANTI-TIP DEVICE

All ranges can tip and injury could result.

To prevent accidental tipping of the range, attach it to the wall and floor by installing the Anti-Tip device supplied.

If the Anti-Tip device supplied with the range does not fit this application, use the universal Anti-Tip device WB02X7909.

To check if the device is installed and engaged properly, remove the kick panel or storage drawer and inspect the rear leveling leg. Make sure it fits securely into the slot.

If you pull the range out from the wall for any reason, make sure the device is properly engaged when you push the range back against the wall. If it is not, there is a possible risk of the range tipping over and causing injury if you or a child stand, sit or lean on an open door.

Please refer to the Anti-Tip device information in this manual. Failure to take this precaution could result in tipping of the range and injury.

GEAppliances.com

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of potential exposure to such substances.

The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during the cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation fan or hood.

Fluorescent light bulbs contain mercury. If your model has a surface light, you must recycle the fluorescent light bulb according to local, state and federal codes.

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

Instructions Operating Instructions Safety

???Use this appliance only for its intended purpose as described in this Owner???s Manual.

???Be sure your appliance is properly installed and grounded by a qualified installer in accordance with the provided installation instructions.

???Have the installer show you the location of the circuit breaker or fuse. Mark it for easy reference.

???Do not attempt to repair or replace any part of your range unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician.

???Before performing any service, disconnect the range power supply at the household distribution panel by removing the fuse or switching off the circuit breaker.

???Do not leave children alone???children should not be left alone or unattended in an area where an appliance is in use. They should never be allowed to sit or stand on any part of the appliance.

???Do not allow anyone to climb, stand or hang on the door, storage drawer or cooktop. They could damage the range and even tip it over, causing severe personal injury.

Support Consumer Tips Troubleshooting Cleaning and Care

Safety Instructions

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

SAFETY PRECAUTIONS

Do not operate the oven or cooktop controls if the glass is broken. Food splatter or cleaning solution may penetrate a broken control panel and create a risk of electrical shock. Contact a qualified technician immediately should your glass control panel become broken.

Support Troubleshooting Tips Care and Cleaning Operating Instructions

???Do not store flammable materials in an oven or near the cooktop.

???CAUTION: Items of interest to children should not be stored in cabinets above a range or on the backsplash of a range???children climbing on the range to reach items could be seriously injured.

???Never wear loose-fitting or hanging garments while using the appliance.

Be careful when reaching for items stored over the range. Flammable material could be ignited if brought in contact with hot surface units or heating elements and may cause severe burns.

???Use only dry pot holders???moist or damp pot holders on hot surfaces may result in burns from steam. Do not let pot holders touch hot surface units or heating elements. Do not use a towel or other bulky cloth in place of pot holders.

???Do not use water on grease fires. Never pick up a flaming pan. Turn the controls off. Smother a flaming pan on a surface unit by covering the pan completely with a well-fitting lid, cookie sheet or flat tray. Use a multi-purpose dry chemical or foam-type fire extinguisher.

???Flaming grease outside a pan can be put out by covering it with baking soda or, if available, by using a multi-purpose dry chemical or foam-type fire extinguisher.

???Flame in the oven can be smothered completely by closing the oven door and turning the oven off or by using a multi- purpose dry chemical or foam-type fire extinguisher.

???For your safety, never use your appliance for warming or heating the room.

???Do not let cooking grease or other flammable materials accumulate in or near the range.

???Do not touch the surface units, the heating elements or the interior surface of the oven. These surfaces may be hot enough to burn even though they are dark in color. During and after use, do not touch, or let clothing or other flammable materials contact the surface units, areas nearby the surface units or any interior area of the oven; allow sufficient time for cooling first.

???Potentially hot surfaces include the cooktop, areas facing the cooktop, oven vent opening, surfaces near the opening, crevices around the oven door.

???REMEMBER: The inside surface of the oven may be hot when the door is opened.

???Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

???Keep the hood and grease filters clean to maintain good venting and to avoid grease fires.

???Teach children not to play with the controls or any other part of the range.

???Always keep dish towels, dish cloths, pot holders and other linens a safe distance from your range.

???Always keep wooden and plastic utensils and canned food a safe distance from your range.

???Always keep combustible wall coverings, curtains or drapes a safe distance from your range.

Consumer

COOK MEAT AND POULTRY THOROUGHLY???

Cook meat and poultry thoroughly???meat to at least an INTERNAL temperature of 160??F. and poultry to at least an INTERNAL temperature of 180??F. Cooking to these temperatures usually protects against foodborne illness.

GEAppliances.com

RADIANT SURFACE UNITS

Use proper pan size???select cookware having flat bottoms large enough to cover the surface unit heating element. The use of undersized cookware will expose a portion of the surface unit to direct contact and may result in ignition of clothing. Proper relationship of cookware to surface unit will also improve efficiency.

Instructions Safety

???Never leave the surface units unattended at high heat settings. Boilovers cause smoking and greasy spillovers that may catch on fire.

???Only certain types of glass, glass ???ceramic, earthenware or other glazed containers are suitable for cooktop service; others may break because of the sudden change in temperature.

???To minimize the possibility of burns, ignition of flammable materials and spillage, the handle of a container should be turned toward the center of the range without extending over nearby surface units.

???Always turn the surface units off before removing cookware.

???When preparing flaming foods under the hood, turn the fan on.

???Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the controls have been turned off.

???Keep an eye on foods being fried at high or medium high heat settings.

???Foods for frying should be as dry as possible. Frost on frozen foods or moisture on fresh foods can cause hot fat to bubble up and over the sides of the pan.

???Use little fat for effective shallow or deep fat frying. Filling the pan too full of fat can cause spillovers when food is added.

???If a combination of oils or fats will be used in frying, stir together before heating, or as fats melt slowly.

???Always heat fat slowly, and watch as it heats.

???Use a deep fat thermometer whenever possible to prevent overheating fat beyond the smoking point.

???Avoid scratching the glass cooktop.

The cooktop can be scratched with items such as sharp instruments, rings or other jewelry, and rivets on clothing.

???Do not operate the radiant surface units if the glass is broken. Spillovers or cleaning solution may penetrate a broken cooktop and create a risk of electrical shock. Contact a qualified technician immediately should your glass cooktop become broken.

???Never use the glass cooktop surface as a cutting board.

???Do not place or store items that can melt or catch fire on the glass cooktop, even when it is not being used.

???Be careful when placing spoons or other stirring utensils on glass cooktop surface when it is in use. They may become hot and could cause burns.

???Clean the cooktop with caution. If a wet sponge or cloth is used to wipe spills on a hot surface unit, be careful to avoid steam burns. Some cleaners can produce noxious fumes if applied to a hot surface.

NOTE: We recommend that you avoid wiping any surface unit areas until they have cooled and the indicator light has gone off. Sugar spills are the exception to this. Please see the Cleaning the glass cooktop section.

???When the cooktop is cool, use only the recommended cleaning cream to clean the cooktop.

???To avoid possible damage to the cooking surface, do not apply cleaning cream to the glass surface when it is hot.

???After cleaning, use a dry cloth or paper towel to remove all cleaning cream residue.

???Read and follow all instructions and warnings on the cleaning cream labels.

???Large scratches or impacts to glass doors or cooktops can lead to broken or shattered glass.

Support Consumer Tips Troubleshooting Cleaning and Care Instructions Operating

Safety Instructions

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

OVEN

Stand away from the range when opening the oven door. Hot air or steam which escapes can cause burns to hands, face and/or eyes.

and Cleaning Operating Instructions

???Do not heat unopened food containers. Pressure could build up and the container could burst, causing an injury.

???Keep the oven vent unobstructed.

???Keep the oven free from grease buildup.

???Place the oven shelf in the desired position while the oven is cool. If shelves must be handled when hot, do not let pot holder contact the heating elements.

???When using cooking or roasting bags in the oven, follow the manufacturer???s directions.

???Pulling out the shelf to the stop-lock is a convenience in lifting heavy foods.

It is also a precaution against burns from touching hot surfaces of the door or oven walls.

???Do not use the oven to dry newspapers. If overheated, they can catch on fire.

???Do not use the oven for a storage area. Items stored in an oven can ignite.

???Do not leave paper products, cooking utensils or food in the oven when not in use.

???Do not use aluminum foil to line oven bottoms, except as suggested in this manual. Improper installation of aluminum foil may result in a risk of electric shock or fire.

Tips Care

SELF-CLEANING OVEN

Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind should be used in or around any part of the oven. Residue from oven cleaners will damage the inside of the oven when the self-clean cycle is used.

Troubleshooting

???Do not clean the door gasket. The door gasket is essential for a good seal. Care should be taken not to rub, damage or move the gasket.

???Before self-cleaning the oven, remove the broiler pan, grid and other cookware.

???Be sure to wipe up excess spillage before starting the self-cleaning operation.

???If the self-cleaning mode malfunctions, turn the oven off and disconnect the power supply. Have it serviced by a qualified technician.

???Clean only parts listed in this Owner???s Manual.

Consumer Support

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

Throughout this manual, features and appearance may vary from your model.

Safety

At both OFF and HI the control clicks into position. You may hear slight clicking sounds during cooking, indicating the control is maintaining your desired setting.

Be sure you turn the control knob to OFF when you finish cooking.

How to Set

Push the knob in and turn in either direction to the setting you want.

A HOT COOKTOP indicator light will glow when any radiant element is turned on, and will remain on until the surface is cooled to approximately 150??F.

Indicator light will:

???come on when the unit is turned on or hot to the touch.

???stay on even after the unit is turned off.

???glow until the unit is cooled to approximately 150??F.

The WM (warm) setting (on some models) on the right REAR surface unit keeps already heated food warm until ready to serve.

Instructions Operating Instructions

Dual Surface Unit (on some models)

The dual surface unit has 2 cooking sizes to select from so you can match the size of the unit to the size of the cookware you are using.

To use the small (5 or 6 inch) surface unit, push in the SMALL BURNER portion of the switch above the control knob.

To use the large (8 or 9 inch) surface unit, push in the LARGE BURNER portion of the switch above the control knob.

Support Consumer Tips Troubleshooting Cleaning and Care

Instructions

Using the surface units.

Throughout this manual, features and appearance may vary from your model.

Cleaning Operating Instructions Safety

SURFACE

COOKING

Never cook directly on the glass. Always use cookware.

OFF CENTER

Always place the pan in the center of the surface unit you are cooking on.

About the radiant surface units???

The radiant cooktop features heating units beneath a smooth glass surface.

NOTE: A slight odor is normal when a new cooktop is used for the first time. It is caused by the heating of new parts and insulating materials and will disappear in a short time.

NOTE: On models with light colored glass cooktops, it is normal for the cooking zones to change color when hot or cooling down. This is temporary and will disappear as the glass cools to room temperature.

The surface unit will cycle on and off to maintain your selected control setting.

It is safe to place hot cookware on the glass surface even when the cooktop is cool.

Even after the surface units are turned off, the glass cooktop retains enough heat to continue cooking. To avoid over-cooking, remove pans from the surface units when the food is cooked. Avoid placing anything on the surface unit until it has cooled completely.

???Water stains (mineral deposits) are removable using the cleaning cream or full strength white vinegar.

???Use of window cleaner may leave an iridescent film on the cooktop. The cleaning cream will remove this discoloration.

???Don???t store heavy items above the cooktop. If they drop onto the cooktop, they can cause damage.

???Do not use the surface as a cutting board.

Tips Care and

DRAGGING

Do not slide cookware across the cooktop because it can scratch the glass???the glass is scratch resistant, not scratch proof.

Consumer Support Troubleshooting

Temperature Limiter

Every radiant surface unit has a temperature limiter.

The temperature limiter protects the glass cooktop from getting too hot.

The temperature limiter may cycle the units off for a time if:

???The pan boils dry.

???The pan bottom is not flat.

???The pan is off center.

???There is no pan on the unit.

The following information will help you choose cookware which will give good performance on glass cooktops.

Safety

Check pans for flat bottoms by using a straight edge.

Stainless Steel:

recommended

Aluminum:

heavy weight recommended

Good conductivity. Aluminum residues sometimes appear as scratches on the cooktop, but can be removed if cleaned immediately. Because of its low melting point, thin weight aluminum should not be used.

Copper Bottom:

recommended

Copper may leave residues which can appear as scratches. The residues can be removed, as long as the cooktop is cleaned immediately. However, do not let these pots boil dry. Overheated metal can bond to glass cooktops. An overheated copper bottom pot will leave a residue that will permanently stain the cooktop if not removed immediately.

Glass-ceramic:

usable, but not recommended

Poor performance. May scratch the surface.

Stoneware:

usable, but not recommended

Poor performance. May scratch the surface.

Home Canning Tips:

Be sure the canner is centered over the surface unit.

Make sure the canner is flat on the bottom.

Use recipes and procedures from reputable sources. These are available from manufacturers such as Ball?? and Kerr?? and the Department of Agriculture Extension Service.

To prevent burns from steam or heat, use caution when canning.

Cleaning and Care Instructions Operating Instructions

Pans with rounded, curved, ridged or warped bottoms are not recommended.

Porcelain Enamel Covered Cast Iron:

recommended

As long as the cookware is covered completely with porcelain enamel, this cookware is recommended. Caution is recommended for cast iron cookware that is not completely covered with smooth porcelain enamel, as it may scratch the glass ceramic cooktop.

Troubleshooting

Wok Cooking

We recommend that you use only a flat-bottomed wok. They are available at your local retail store.

Do not use woks that have support rings.

Do not use round bottom woks. You could be seriously burned if the wok tipped over.

Use only flat-bottomed woks.

Support Consumer Tips

Operating Instructions Safety Instructions

Using the oven controls.

Throughout this manual, features and appearance may vary from your model.

Oven Control, Clock and Timer Features and Settings

Cleaning

COOK TIME ON/OFF Pad

Press this pad and then press the HOUR and MIN. pads to set the amount of time you want your food to cook. Turn the Oven Temperature knob to the desired temperature. The oven will shut off when the Cook Time has run out.

PREHEATED Light

Glows when the oven reaches your selected temperature.

On some models, opening the oven door will not automatically turn the oven light on. You may use the oven light switch to turn the light on and off.

Care and

TIMER ON/OFF Pad

Press this pad to select the timer feature.

AUTOMATIC OVEN Light

This lights anytime the oven has been programmed to automatically turn on or off.

CLEAN Light

Glows when the oven is in the self-clean cycle. After the self-clean cycle, the light will flash. Unlatch the door and turn the Oven Temperature knob to OFF.

Do not lock the oven door with the latch during cooking. The latch is used for self-cleaning only.

Consumer Support Troubleshooting Tips

HOUR and MIN. Pads

These pads allow you to set times up to 11 hours and 59 minutes.

As a safety feature, this oven will automatically shut off after 12 hours. On models with touch pad clock controls this feature may be deactivated to allow the oven to be left on for more than 12 hours. To deactivate or reactivate the Automatic Oven Shut-Off, press and hold both the MIN. +/??? pads for about 4 seconds.

OVEN ON Light

Glows anytime the oven is heating. The light will flash when the oven automatically turns off to remind you to turn the Oven Temperature knob to OFF.

Oven Temperature Knob

Turn this knob to the setting you want. (On some models, you must push the knob in before turning.) The temperature will be displayed to indicate setting. Display will change back to time after a few seconds.

TEMP RECALL

Press the ??? pad above TEMP RECALL to display the selected oven temperature.

Display

Shows the time of day and the time set for the timer.

If ???F??? and a number or letter??? flash in the display and the oven control signals, this indicates a function error code.

If your oven was set for a timed oven operation and a power outage occurred, the clock and all programmed functions must be reset.

The time of day will flash in the display when there has been a power outage.

CLOCK Pad

Press this pad before setting the clock.

START TIME ON/OFF Pad

Press this pad and the HOUR and MIN. pads to delay the starting of your oven up to 11 hours and 59 minutes.

To avoid possible burns, place the shelves in the desired position before you turn the oven on.

Safety

The oven has 6 shelf positions.

Before you begin???

The shelves have stops, so that when placed correctly on the supports, they will stop before coming completely out, and will not tilt.

When placing and removing cookware, pull the shelf out until it stops.

To remove a shelf, pull it toward you, tilt the front end up and pull it out.

To replace, place the end of the shelf (stop-locks) on the support, tilt up the front and push the shelf in.

CAUTION: When you are using the shelf in the lowest position (A), you will need to use caution when pulling the shelf out. We recommend that you pull the shelf out several inches and then, using two pot holders, pull the shelf out by holding the sides of it. The shelf is low and you could be burned if you place your hand in the middle of the shelf and pull all the way out. Be very careful not to burn your hand on the door when using the shelf in the lowest position (A).

Instructions Operating Instructions

How to Set the Oven for Baking or Roasting

Turn the Oven Temperature knob to the temperature you desire.

On some models, you must push the knob in before turning.

Check food for doneness at minimum time on recipe. Cook longer if necessary.

and Care

Turn the Oven Temperature knob

Preheating and Pan Placement

Cleaning

Center baking pans in the oven

Preheat the oven if the recipe calls for it. Preheating is necessary for good results when baking cakes, cookies, pastry and breads.

To preheat, set the oven at the correct temperature. The control will beep when the oven is preheated and the display will show your set temperature. This will take approximately 6???10 minutes.

Baking results will be better if baking pans are centered in the oven as much as possible. If baking with more than one pan, place the pans so each has at least 1 to 11???2 ??? of air space around it. If baking four cake layers at the same time, place two layers on rack B and two layers on rack D. Stagger the pans on the rack so one is not directly above the other.

Tips Troubleshooting

Do not use aluminum foil on the bottom of the oven.

Never entirely cover a shelf with aluminum foil. This will disturb the heat circulation and result in poor baking.

A smaller sheet of foil may be used to catch a spillover by placing it on a lower shelf several inches below the food.

Support Consumer

Not all features are on all models.

Safety

Make sure the clock is set to the correct time of day.

To Set the Clock

The clock must be set to the correct time of day for the automatic oven timing functions to work properly. The time of day cannot be changed during a timed baking or self-cleaning cycle.

Press the CLOCK pad.

Press the HOUR and MIN. pads until the time of day shows in the display.

Operating Instructions

To Black-Out the Clock

If you have several clocks in your kitchen, you may wish to black-out the time of day display of your range. If so, press the

CLOCK pad.

Press the CLOCK pad twice to retain the time of day after a black-out.

Although you cannot see it, the clock maintains the correct time of day. It will reappear for the duration of any function that displays a Start Time or Cook Time. Press the CLOCK pad again to bring back the display.

Instructions

To Set the Timer

The timer does not control oven operations.

The maximum setting on the timer is 11 hours and 59 minutes.

Cleaning and Care

To Reset the Timer

If the display is still showing the time remaining, you may change it by pressing the HOUR and MIN. pads until the time you want appears in the display.

If the remaining time is not in the display, recall the remaining time by pressing the TIMER ON/OFF pad and then pressing the HOUR and MIN. pads until the new time you want shows in the display.

Troubleshooting

To Cancel the Timer

Press the TIMER ON/OFF pad twice.

End of Cycle Tones

Clear the tones by pressing the pad of the function you are using.

Support Consumer Tips

Safety Instructions

Using the timed baking and roasting features.

Do not latch the oven door during timed cooking. The latch is used for self-cleaning only.

NOTE: Foods that spoil easily???such as milk, eggs, fish, stuffings, poultry and pork???should not be allowed to sit for more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

Operating Instructions

The oven will turn on immediately and cook for a selected length of time. At the end of the cooking time the oven will turn off automatically.

Press the COOK TIME ON/OFF pad.

Using the HOUR and MIN. pads, enter the length of cooking time.

Turn the Oven Temperature knob to the desired temperature.

On some models, you must push the knob in before turning.

The display will show the cooking time remaining. When the oven reaches the set temperature, a tone sounds.

When the oven automatically turns

off the AUTOMATIC OVEN light will flash and the oven will signal. Turn the oven control to OFF to stop the flashes and signal.

How to Set a Delayed Start and Automatic Stop

You can set the oven control to delay-start the oven, cook for a specific length of time and then turn off automatically.

Make sure the clock shows the correct time of day.

Press the START TIME ON/OFF pad.

Using the HOUR and MIN. pads, enter the time you want cooking to start.

Press the COOK TIME ON/OFF pad.

When the oven automatically turns off the AUTOMATIC OVEN light will flash and the oven will signal. Turn the oven control to OFF to stop the flashes and signal.

Consumer Support Troubleshooting Tips Care and Cleaning

Using the HOUR and MIN. pads, enter the length of cooking time.

Turn the Oven Temperature knob to the desired temperature.

On some models, you must push the knob in before turning.

Using the Sabbath Feature.

(Designed for use on the Jewish Sabbath and Holidays) (On some models)GEAppliances.com

The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning, or Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on the control panel, the oven light may be turned on and left on.

How to Set for Regular Baking/Roasting

Instructions Safety

Make sure the clock shows the correct time of day and the oven is off.

Press and hold both the MIN. + AND - pads, at the same time, until the display changes.

Press and hold either the MIN. + OR - pad until the display changes, then release the pad. If SAb appears in the display, go to the next step. If SAb is not in the display, continue to press, hold and release the pad until SAb appears.

Turn the Oven Temperature knob to the desired temperature between

warm (WM) and 550??. The display will show ???.

After a random delay period of approximately 30 seconds to 1 minute,

the display, reset the temperature.

To adjust the oven temperature, turn the Oven Temperature knob to the desired temperature.

NOTE: The COOK TIME ON/OFF pad is active during the Sabbath feature.

Instructions Operating

How to Set for Timed Baking/Roasting???Immediate Start and Automatic Stop

Care

Make sure the clock shows the correct time of day and the oven is off.

Press and hold both the MIN. + AND - pads, at the same time, until the display changes.

Press the COOK TIME ON/OFF pad.

Immediately enter the length of cooking time, using the HOUR and MIN. pads. The cooking time that you entered will be displayed.

Turn the Oven Temperature knob to the desired temperature. The display will show ???.

After a random delay period of approximately 30 seconds to 1 minute,

the display, reset the temperature.

To adjust the oven temperature, turn the Oven Temperature knob to the desired temperature.

When cooking is finished, the display will

oven has turned OFF but is still set in Sabbath. Remove the cooked food.

Troubleshooting Cleaning and

How to Exit the Sabbath Feature

Tips

Turn the Oven Temperature knob to OFF.

If the oven is cooking, wait for a random time delay of approximately 30 seconds to 1 minute until only ??? is in the display.

Press and hold both the MIN. + AND - pads, at the same time, until the display changes.

Press and hold either the MIN. + OR - pad until the display changes, then release the pad. Continue to press, hold and release the pad until ON or OFF

appears for your preference of 12 hour automatic oven shut-off. ON indicates that the 12 hour automatic oven shut-off is turned on and OFF indicates that the 12 hour automatic oven shut-off is turned off.

Press the CLOCK pad to return to the time of day.

NOTE: If a power outage occurred when the oven was in Sabbath mode, the oven will automatically turn off and the oven control must be reset.

Support Consumer

Safety Instructions

Adjust the oven thermostat???Do it yourself!

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks

to become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven. These thermometers may vary 20???40??F.

Cleaning Operating Instructions

To Adjust the Thermostat

Put the Oven Temperature knob in the OFF position.

Press and hold the HOUR +/??? pads for 5 seconds until the display changes.

Before display changes back, press the HOUR +/??? pads to increase or decrease the temperature in 5 degree increments.

The oven temperature can be adjusted up as much as 35??F. or down as much as 35??F.

If the oven adjustment is set cooler than the factory setting a minus sign (???) and the adjusted temperature will appear in the display.

Wait several seconds for the control to automatically set and return to its previous setting.

NOTE: This adjustment will not affect the broiling or the self-cleaning temperatures. The adjustment will be retained after a power failure.

Consumer Support Troubleshooting Tips Care and

The type of margarine will affect baking performance!

Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat). If you decrease the fat, the recipe may not give the same results as with a higher fat product.

Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the fat content of a spread product, the more noticeable these differences become.

Federal standards require products labeled ???margarine??? to contain at least 80% fat by weight. Low fat spreads, on the other hand, contain less fat and more water. The high moisture content of these spreads affects the texture and flavor of baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing at least 70% vegetable oil.

Never force the latch handle. Forcing the handle will damage the door lock mechanism.

Safety

Wipe up heavy soil on the oven bottom.

Before a Clean Cycle

We recommend venting your kitchen with an open window or using a ventilation fan or hood during the first self-clean cycle.

Remove the shelves, broiler pan, broiler grid, all cookware and any aluminum foil from the oven.

The oven shelves can be self-cleaned, but they will darken, lose their luster and become hard to slide.

Soil on the front frame of the range and outside the gasket on the door will need to be cleaned by hand. Clean these areas with hot water, soap-filled steel-wool pads or cleansers such as Soft Scrub??. Rinse well with clean water and dry.

Do not clean the gasket. The fiberglass material of the oven door gasket cannot withstand abrasion. It is essential for the gasket to remain intact. If you notice it becoming worn or frayed, replace it.

Wipe up any heavy spillovers on the oven bottom.

Make sure the oven light bulb cover is in place and the oven light is off.

IMPORTANT: The health of some birds is extremely sensitive to the fumes given off during the self-cleaning cycle of any range. Move birds to another well ventilated room.

Instructions Operating Instructions

How to Set the Oven for Cleaning

Latch the door.

Turn the Oven Temperature knob to CLEAN.

On some models, you must push the knob in before turning.

Clean cycle time is normally 4 hours and 20 minutes. On models with COOK TIME and START TIME pads, you can change the clean time to between 3 hours and 5 hours, 59 minutes by using the HOUR and MIN. pads. The display will show the clean time counting down.

When the CLEAN light flashes, slide the latch handle to the left, and turn the Oven Temperature knob to OFF.

To stop a clean cycle, turn the Oven Temperature knob to OFF. Wait until the oven has cooled and unlatch the door.

???While the oven is self-cleaning, you can press the CLOCK pad to display the time of day. To return to the clean countdown, press the COOK TIME ON/OFF pad.

Support Consumer Tips Troubleshooting Cleaning and Care

Care and Cleaning Operating Instructions Safety Instructions

Using the self-cleaning oven.

How to Delay the Start of Cleaning

Make sure the clock shows the correct time of day.

Latch the door.

Turn the Oven Temperature knob to CLEAN.

On some models, you must push the knob in before turning.

Press the START TIME ON/OFF pad.

Press the HOUR and MIN. pads to set the time cleaning will start.

When the CLEAN light flashes, slide the latch handle to the left as far as it will go and turn the Oven Temperature knob to OFF.

Consumer Support Troubleshooting Tips

After a Clean Cycle

You may notice some white ash in the oven. Wipe it up with a damp cloth after the oven cools.

If white spots remain, remove them with a soap- filled steel wool pad and rinse thoroughly with a vinegar and water mixture.

These deposits are usually a salt residue that cannot be removed by the clean cycle.

If the oven is not clean after one clean cycle, repeat the cycle.

???You cannot set the oven for cooking until the oven is cool enough for the door to be unlatched.

???If the shelves become hard to slide, apply a small amount of vegetable oil or cooking oil to a paper towel and wipe the edges of the oven shelves with the paper towel.

Be sure all controls are off and all surfaces are cool before cleaning any part of the range.

If your range is removed for cleaning, servicing or any reason, be sure the anti-tip device is re-engaged properly when the range is replaced. Failure to take this precaution could result in tipping of the range and cause injury.

Instructions Safety

How to Remove Packaging Tape

To assure no damage is done to the finish of the product, the safest way to remove the adhesive left from packaging tape on new appliances is an application of a household liquid dishwashing detergent, mineral oil or cooking oil.

Apply with a soft cloth and allow to soak. Wipe dry and then apply an appliance polish to thoroughly clean and protect the surface.

NOTE: The plastic tape (on some models) must be removed from all chrome trim. It cannot be removed if it is baked on.

Instructions Operating

Control Knobs

To Remove:

Be sure the knob is in the OFF position.

Pull straight off the stem. Using a piece of string can make removing the knob easier. Slip the string under and around the knob,

pull straight out.

Wash the knob thoroughly with warm soapy water. Dry completely with a soft cloth. DO NOT let the knob soak.

To Replace:

Check the back of the knob.

The molded rib of the knob is designed to fit perfectly onto the knob stem.

Align the molded rib to the clear groove in the knob stem. Push the knob back as far as it will go.

Cleaning and Care

Control Panel

Support Consumer Tips Troubleshooting

Instructions Safety

Oven Vent

The oven vent is located behind the right rear surface unit.

This area could become hot during oven use.

It is normal for steam to come out of the vent and moisture may collect underneath it when the oven is in use.

The vent is important for proper air circulation. Never block this vent.

Instructions Operating

Oven Shelves

Clean the oven shelves with an abrasive cleanser or steel wool. After cleaning, rinse the shelves with clean water and dry with a clean cloth.

NOTE: The oven shelves may be cleaned in the self-cleaning oven. However, the shelves will darken in color, lose their luster and become hard to slide if cleaned during the self-cleaning cycle.

To make the shelves slide more easily apply a small amount of vegetable oil or cooking oil to a paper towel and wipe the edges of the oven shelves with the paper towel.

Support Consumer Tips Troubleshooting Cleaning and Care

Instructions

Care and cleaning of the range.

Operating Instructions Safety

Oven Light Replacement

CAUTION: Before replacing your oven light bulb, disconnect the electrical power to the range at the main fuse or circuit breaker panel.

Be sure to let the light cover and bulb cool completely.

To remove the cover:

Wire cover holder.

Hold a hand under the cover so it doesn???t fall when released. With fingers of the same hand, firmly push back the wire cover holder. Lift off the cover.

Do not remove any screws to remove the cover.

Replace bulb with a 40-watt appliance bulb.

To replace the cover:

Place it into groove of the light receptacle. Pull wire forward to the center of the cover until it snaps into place.

Connect electrical power to the range.

Tips Care and Cleaning

After broiling, remove the broiler pan from the oven.

Broiler Pan & Grid

Do not clean the broiler pan or grid in a self-cleaning oven.

After broiling, remove the broiler pan from the oven. Remove the grid from the pan. Carefully pour out the grease from the pan into a proper container.

Wash and rinse the broiler pan and grid in hot water with a soap-filled or plastic scouring pad.

If food has burned on, sprinkle the grid with detergent while hot and cover with wet paper towels or a dishcloth. Soaking the pan will remove burned-on foods.

Both the broiler pan and grid may be cleaned with a commercial oven cleaner.

Both the broiler pan and grid can also be cleaned in a dishwasher.

Do not store a soiled broiler pan and grid anywhere in the range.

Consumer Support Troubleshooting

Oven Heating Elements

Do not clean the bake element or the broil element. Any soil will burn off when the elements are heated.

To clean the oven floor, gently lift the bake element. Clean with warm soapy water.

Safety

Clean your cooktop after each spill. Use CERAMA BRYTE?? Ceramic Cooktop Cleaner.

Normal Daily Use Cleaning

ONLY use CERAMA BRYTE?? Ceramic Cooktop Cleaner on the glass cooktop. Other creams may not be as effective.

To maintain and protect the surface of your glass cooktop, follow these steps:

Before using the cooktop for the first time, clean it with CERAMA BRYTE?? Ceramic Cooktop Cleaner. This helps protect the top and makes cleanup easier.

Daily use of CERAMA BRYTE?? Ceramic Cooktop Cleaner will help keep the cooktop looking new.

Shake the cleaning cream well. Apply a few drops of CERAMA BRYTE?? Ceramic Cooktop Cleaner directly to the cooktop.

Use a paper towel or CERAMA BRYTE?? Cleaning Pad for Ceramic Cooktops to clean the entire cooktop surface.

Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse.

NOTE: It is very important that you DO NOT heat the cooktop until it has been cleaned thoroughly.

Instructions Operating Instructions

Use a CERAMA BRYTE?? Cleaning Pad for Ceramic Cooktops or a Scotch-Brite?? Multi-Purpose No Scratch blue scrub pad.

Burned-On Residue

WARNING: DAMAGE to your glass surface may occur if you use scrub pads other than those recommended.

Allow the cooktop to cool.

Spread a few drops of CERAMA BRYTE?? Ceramic Cooktop Cleaner on the entire burned residue area.

Using the included CERAMA BRYTE?? Cleaning Pad for Ceramic Cooktops, rub the residue area, applying pressure as needed.

If any residue remains, repeat the steps listed above as needed.

For additional protection, after all residue has been removed, polish the entire surface with CERAMA BRYTE?? Ceramic Cooktop Cleaner and a paper towel.

Cleaning and Care

The CERAMA BRYTE?? Ceramic Cooktop Scraper and all recommended supplies are available through our Parts Center. See instructions under ???To Order Parts??? section on next page.

NOTE: Do not use a dull or nicked blade.

Heavy, Burned-On Residue

Allow the cooktop to cool.

Use a single-edge razor blade scraper at approximately a 45?? angle against the glass surface and scrape the soil. It will be necessary to apply pressure to the razor scraper in order to remove the residue.

After scraping with the razor scraper, spread a few drops of CERAMA BRYTE?? Ceramic Cooktop Cleaner on the entire burned residue area. Use the CERAMA BRYTE?? Cleaning Pad to remove any remaining residue.

For additional protection, after all residue has been removed, polish the entire surface with CERAMA BRYTE?? Ceramic Cooktop Cleaner and a paper towel.

Support Consumer Tips Troubleshooting

Instructions

Cleaning the glass cooktop.

Metal Marks and Scratches

Instructions Safety

Be careful not to slide pots and pans across your cooktop. It will leave metal markings on the cooktop surface.

These marks are removable using the CERAMA BRYTE?? Ceramic Cooktop Cleaner with the CERAMA BRYTE?? Cleaning Pad for Ceramic Cooktops.

If pots with a thin overlay of aluminum or copper are allowed to boil dry, the overlay may leave black discoloration on the cooktop.

This should be removed immediately before heating again or the discoloration may be permanent.

WARNING: Carefully check the bottom of pans for roughness that would scratch the cooktop.

Cleaning Operating

Cooktop Seal

To clean the cooktop seal around the edges of the glass, lay a wet cloth on it for a few minutes, then wipe clean with nonabrasive cleaners.

Glass surface???potential for permanent damage.

Our testing shows that if you are cooking high sugar

Damage from Sugary Spills and Melted Plastic

mixtures such as jelly or fudge and have a spillover, it can cause permanent damage to the glass surface unless the spillover is immediately removed.

Turn off all surface units. Remove hot pans.

Wearing an oven mitt:

a.Use a single-edge razor blade scraper (CERAMA BRYTE?? Ceramic Cooktop Scraper) to move the spill to a cool area on the cooktop.

b.Remove the spill with paper towels.

Any remaining spillover should be left until the surface of the cooktop has cooled.

Don???t use the surface units again until all of the residue has been completely removed.

NOTE: If pitting or indentation in the glass surface has already occurred, the cooktop glass will have to be replaced. In this case, service will be necessary.

Consumer Support Troubleshooting Tips Care and

To Order Parts

To order CERAMA BRYTE?? Ceramic Cooktop Cleaner and the cooktop scraper, please call our toll-free number:

CERAMA BRYTE??

Ceramic Cooktop Cleaner . . . . . .# WX10X300

CERAMA BRYTE??

Ceramic Cooktop Scraper . . . .# WX10X0302

Kit . . . . . . . . . . . . . . . . . . . . . . . . .# WB64X5027 (Kit includes cream and razor scraper)

CERAMA BRYTE?? Cleaning Pads

for Ceramic Cooktops . . . . . . . . . .#WX10X350

GE Service Protection Plus???

GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus??????comprehensive protection on all your appliances???

No Matter What Brand!

Benefits Include:

???Backed by GE

???All brands covered

???Unlimited service calls

???All parts and labor costs included

???No out-of-pocket expenses

???No hidden deductibles

???One 800 number to call

We???ll Cover Any Appliance.

Anywhere. Anytime.*

You will be completely satisfied with our service protection or you may request your money back on the remaining value of your contract. No questions asked. It???s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more???any brand! Plus there???s no extra charge for emergency service and low monthly financing is available. Even icemaker coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224 for more information.

*All brands covered, up to 20 years old, in the continental U.S.

???Cut here

Please place in envelope and mail to:

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Read your Owner???s Manual carefully. It will help you operate your new appliance properly.

Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register

online at GEAppliances.com.???

Cut here

Consumer Product Ownership Registration

Important

Mail

Today!

*Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important communications from GE Appliances (GEA).

??? Check here if you do not want to receive communications from GEA???s carefully selected partners.

General Electric Company

Louisville, Kentucky

GEAppliances.com

GE Electric Range Warranty.

During this limited additional four-year warranty, you will be responsible for any labor or in-home service.

What GE Will Not Cover:

Instructions Operating Instructions Safety

???Service trips to your home to teach you how to use the product.

???Improper installation.

???Failure of the product if it is abused, misused, or used for other than the intended purpose or used commercially.

???Damage to the glass cooktop caused by use of cleaners other than the recommended cleaning creams.

???Damage to the glass cooktop caused by hardened spills of sugary materials or melted plastic that are not cleaned according to the directions in the Owner???s Manual.

???Replacement of house fuses or resetting of circuit breakers.

???Damage to the product caused by accident, fire, floods or acts of God.

???Incidental or consequential damage caused by possible defects with this appliance.

Cleaning and Care

This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state???s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

Support Consumer Tips Troubleshooting

Consumer Support.

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner???s Manuals, order parts, catalogs, or even schedule service on-line. You can also ???Ask Our Team of Experts??????

your questions, and so much more...

Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.

GE supports the Universal Design concept???products, services and environments that can be used by people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and impairments. For details of GE???s Universal Design applications, including kitchen design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC (800.833.4322).

Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours. GE Consumer Home Services will still be there after your warranty expires.

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at 800.626.2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.

If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations

GE Appliances, Appliance Park Louisville, KY 40225

Register your new appliance on-line???at your convenience! Timely product registration will allow for enhanced communication and prompt service under the terms of your warranty, should the need arise. You may also mail in the pre-printed registration card included in the packing material.

Printed in the United States
