IMPORTANT SAFETY INSTRUCTIONS
When using your flatiron, basic safety precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
1.Use iron only for its intended use.
2.To protect against risk of electric shock, do not immerse the iron in water or other liquids.
3.The iron should always be turned to OFF ( O ) before plugging or unplugging from outlet. Never yank cord to disconnect from outlet; instead, grasp plug and pull to disconnect.
4.Do not allow cord to touch hot surfaces. Let iron cool completely before putting away. Fully retract cord within unit or loop cord loosely around iron, as applicable, when storing.
5.Always disconnect iron from electrical outlet when filling with water or emptying and when not in use.
6.Do not operate iron with a damaged cord or if the iron has been dropped or damaged.
To avoid the risk of electric shock, do not disassemble the iron. Call our
7.Close supervision is necessary for any appliance being used by or near children. Do not leave iron unattended while connected or on an ironing board.
8.Burns can occur from touching hot metal parts, hot water, or steam. Use caution when you turn a steam iron upside down ??? there may be hot water in the reservoir.
SPECIAL INSTRUCTIONS
1.To avoid a circuit overload, do not operate another high wattage appliance on the same circuit.
2.If an extension cord is absolutely necessary, a
SAVE THESE INSTRUCTIONS!
OTHER CONSUMER SAFETY INFORMATION
This product is intended for household use only.
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
Use the iron on an ironing board. Ironing on any other surface may damage that surface. Do not iron or vertical steam clothes that are being worn.
Do not use vertical steam in the direction of people or pets.
2
840165700 Ev02 5/1/07 4:05 PM Page 3
PARTS AND FEATURES
Adjustable Steam
Spray/Blast Buttons
Blast Spray
BEFORE FIRST USE
???Steam vents should be cleaned before first use.
???During the first use of the iron, it may appear to smoke. This will stop and does not indicate a defect or hazard.
???To clean steam vents before first use, prepare iron for steam ironing, then iron over an old cloth for a few minutes while letting the iron steam. Press the Blast button several times to clean the vents. Then follow the
???Many irons spit or sputter during the first few uses with tap water. This happens as the steam chamber becomes conditioned. This will stop after a few uses.
3
840165700 Ev02 5/1/07 4:05 PM Page 4
TO DRY IRON
1.Plug iron into outlet.
2.Turn Adjustable Steam Switch to Dry Iron O.
3.Turn Temperature Control Dial to desired temperature. Allow two minutes for iron to reach desired temperature.
4.To turn iron OFF (O), turn Temperature Control Dial to OFF (O) and unplug iron.
TO STEAM IRON
1.Unplug iron. Turn Adjustable Steam Switch to Dry Iron O. Set iron upright on heel rest.
2.Using a cup, slowly pour tap water into water tank opening until MAX fill line has been reached. Do not fill iron directly from the faucet.
3.Plug iron into outlet.
4.Turn the Temperature Control Dial to desired fabric setting in the steam range.
5.Allow two minutes for the iron to reach desired temperature.
6.Set Adjustable Steam Switch to the recommended steam level. See the ???Fabric Setting Chart.???
7.To turn iron off, set Adjustable Steam Switch to Dry Iron O. Turn the Temperature Control Dial to OFF ( O ). Unplug iron.
8.Empty water from the iron following directions in ???Caring for Your Iron.???
Water
Please use ordinary tap water. If you have extremely hard water, alternate between tap water and distilled water for use in the iron.
FABRIC SETTING CHART
Steam
Setting
4
840165700 Ev02 5/1/07 4:05 PM Page 5
CARING FOR YOUR IRON
Iron
1.The water tank of your iron should be emptied after each use. Turn Temperature Control Dial to OFF ( O ). Unplug the iron and hold over a sink. Slowly tilt pointed end of iron down over sink. Water will run out of water tank opening.
2.After iron has completely cooled, fully retract cord into iron or loop cord loosely around iron, as applicable, and store in an upright position. NOTICE: Do not store iron laying flat on soleplate.
Soleplate
1.Never iron over zippers, pins, metal rivets, or snaps, as these may scratch the soleplate.
2.To clean occasional
3.Always store iron upright in the heel rest position.
To keep the steam vents clear of any
1.Turn Temperature Control Dial to OFF ( O ) and set Adjustable Steam Switch to Dry Iron O. Fill iron with water to 1???2 of its maximum capacity.
2.Turn Temperature Control Dial to Linen setting and let iron heat for 2 minutes. Keep Adjustable Steam Switch on Dry Iron O.
3.Turn Temperature Control Dial to OFF ( O ). Unplug iron and hold over a sink with soleplate facing down.
4.Turn Adjustable Steam Switch to MAX, while pressing Blast of Steam button often. Boiling water and steam will flow out of steam vents. Allow all water to drain from iron.
5.Gently move iron front to back to allow water to clean entire soleplate area.
6.If water still remains inside of soleplate, reheat iron as indicated in Step 2. Boiling water and steam could still flow out of steam vents.
5
840165700 Ev02 5/1/07 4:05 PM Page 6
FEATURES (on selected models)
Adjustable Steam Switch
This knob provides steam for fabrics such as wool and linen. See the ???Fabric Setting Chart??? for details. Set the switch to Dry Iron O to iron without steam.
Spray and Blast of Steam Buttons
Push Blast Button for an extra blast of steam. Push Spray Button to release a fine spray of water for difficult wrinkles in cotton or linen.
Power ON/ Auto Shutoff Reset Button/Light
This light comes on when the iron is first plugged in. After one hour, the iron will shut off and the light will go out. Push the Reset Button/Light to turn the iron back on.
Power On Light
On units not provided with Auto Shutoff, this light comes on when the iron is plugged in and remains on until the iron is unplugged. The light stays on even if Temperature Control Dial is turned to OFF ( O ).
Retractable Cord
1. Pull cord to desired length. Do not unwind cord beyond colored tape indicator on cord.
2. To store cord, press and hold the Cord Release Button while guiding the cord into the storage area.
w WARNING: To reduce the risk of an eye injury, hold the plug while retracting the cord.
6
840165700 Ev02 5/1/07 4:05 PM Page 7
Retractable cord will not unwind (on select models).
???Rewind a small amount of cord then fully depress the Cord Release Button and pull the cord to desired length.
7
840165700 Ev02 5/1/07 4:05 PM Page 8
CUSTOMER SERVICE
If you have a claim under this warranty, please call our Customer Assistance Number. For faster service please have model, series, and type numbers ready for operator to assist you. These numbers can be found on the bottom of your appliance.
MODEL: ________________ TYPE: _________________ SERIES: ________________
Customer Assistance Number
For more information, please visit us at www.walmart.com
What does your warranty cover?
??? Any defect in material or workmanship.
For how long after the original purchase?
??? Two years.
What will we do?
???Provide you with a new one.
???For those items still under warranty but no longer available,
How do you make a warranty claim?
???Save your receipt.
???Properly pack your unit. We recommend using the original carton and packing materials.
???Return the product to your nearest
What does your warranty not cover?
??? Parts subject to wear, including, without limitation, glass parts, glass containers, cutter/strainer, blades, seals, gaskets, clutches, motor brushes, and/or agitators, etc.
??? Commercial use or any other use not found in printed directions.
??? Damage from misuse, abuse, or neglect, including failure to clean product regularly in accordance with manufacturer???s
instructions.
g
How does state law relate to this warranty?
???This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.
???THIS WARRANTY IS IN LIEU OF ANY OTHER
WARRANTY OR CONDITION, WHETHER
EXPRESS OR IMPLIED, WRITTEN OR ORAL,
INCLUDING, WITHOUT LIMITATION, ANY
STATUTORY WARRANTY OR CONDITION OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
???
MANUFACTURER EXPRESSLY DISCLAIM ALL
RESPONSIBILITY FOR SPECIAL, INCIDENTAL,
AND CONSEQUENTIAL DAMAGES OR LOSSES
CAUSED BY USE OF THIS APPLIANCE. ANY
LIABILITY IS EXPRESSLY LIMITED TO AN
AMOUNT EQUAL TO THE PURCHASE PRICE
PAID WHETHER A CLAIM, HOWEVER
INSTITUTED, IS BASED ON CONTRACT,
INDEMNITY, WARRANTY, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY, OR OTHER-
WISE. SOME STATES OR PROVINCES DO NOT
ALLOW THIS EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL LOSSES
SO THE FOREGOING DISCLAIMER MAY NOT
APPLY TO YOU.
What if you encounter a problem with this product while using it outside the country of purchase?
???The warranty is valid only in the country of purchase and you follow the warranty claim procedure as noted.
