Food Freezers

Owner???s Manual &

Installation Instructions

Chest???Manual

Defrost Models:

FCM5

FCM7

FCM9

197D3355P002 49-60260 08-03 JR

Safety Instructions

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

Use this appliance only for its intended purpose as described in this Owner???s Manual.

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions

???This freezer must be properly installed and located in accordance with the Installation Instructions before it is used.

???Do not allow children to climb, stand or hang on the shelves in the freezer. They could damage the freezer and seriously injure themselves.

???After your freezer is in operation, do not touch the cold surfaces, particularly when hands are damp or wet. Skin may stick to these extremely cold surfaces.

???Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

???Unplug the freezer before cleaning, making repairs or changing the light bulb.

NOTE: We strongly recommend that any servicing be performed by a qualified individual.

???Turning the control to the OFF position does not remove power to the light circuit on models with interior light.

???Do not refreeze frozen foods which have thawed completely.

???The maximum amount of food your freezer is designed to freeze at one time is approximately 3 pounds (1.5 kg) per cubic foot of freezer capacity. In normal position, your freezer???s temperature control will maintain sufficiently low temperatures in the freezer to freeze recommended quantities of food.

???Caution should be used when removing the door of a freezer. Particular caution should be used when removing the lid of a Chest freezer, as most Chest freezer lids are under spring tension. Contact the manufacturer???s representative for

a method of safe removal.

2

www.GEAppliances.com

DANGER! RISK OF CHILD ENTRAPMENT

PROPER DISPOSAL OF THE FREEZER

When using electrical appliances, basic safety precautions should be followed, including the following:

Instructions Safety

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators and freezers are still dangerous???even if they will sit for ???just a few days.??? If you are getting rid of your old refrigerator or freezer, please follow the instructions below to help prevent accidents.

Before You Throw Away Your Old

Refrigerator or Freezer:

???Take off the doors.

???Leave the shelves in place so that children may not easily climb inside.

Refrigerants

All refrigeration products contain refrigerants, which under federal law must be removed prior to product disposal. If you are getting rid of an old refrigeration product, check with the company handling the disposal about what to do.

Instructions Operating

USE OF EXTENSION CORDS

Because of potential safety hazards under certain conditions, we strongly recommend against the use of an extension cord.

However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United States) or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.

3

Support Consumer Tips Troubleshooting Instructions Installation

Safety Instructions

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded.

Instructions Operating Instructions

The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock hazard from this appliance.

Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.

If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

The freezer should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate.

This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires.

Never unplug your freezer by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.

Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.

When moving the freezer away from the wall, be careful not to roll over or damage the power cord.

Installation

USE OF ADAPTER PLUGS (Adapter plugs not permitted in Canada)

Because of potential safety hazards under certain conditions, we strongly recommend against the use of an adapter plug.

Troubleshooting Tips

However, if you must use an adapter, where local codes permit, a temporary connection may be made to a properly grounded 2-prong wall outlet by use of a UL-listed adapter available at most local hardware stores.

The larger slot in the adapter must be aligned with the larger slot in the wall outlet to provide proper polarity in the connection of the power cord.

When disconnecting the power cord from the adapter, always hold the adapter in place with one hand while pulling the power cord plug with the other hand. If this is not done, the adapter ground terminal is very likely to break with repeated use.

If the adapter ground terminal breaks, DO NOT USE the freezer until a proper ground has been established.

Attaching the adapter ground terminal to a wall outlet cover screw does not ground the appliance unless the cover screw is metal, and not insulated, and the wall outlet is grounded through the house wiring. You should have the circuit checked by a qualified electrician to make sure the outlet is properly grounded.

Consumer Support

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

4

Temperature Control
Freezing temperature selection is made by setting the control from 1 to 7 (coldest).
If you want colder or warmer temperatures, adjust the control one step at a time.

Allow several hours after each one-step adjustment for the freezer temperature to stabilize.

Turning the control to the OFF position stops the cooling process but does not shut off power to the freezer.

Installation Instructions Operating Instructions Safety

Temperature Monitor/High-Temp Alarm Switch (on some models)

Located on front of freezer.

ON OFF

HIGH-TEMP

ALARM SWITCH

An alarm will sound if the freezer temperature reaches unsafe levels. The alarm operates on household electricity. If the power fails, the alarm will not perform.

An ON/OFF switch allows the temperature alarm to be deactivated if desired. The freezer is shipped with the switch in the OFF position. After the freezer has run long enough to lower the temperature, you may set the switch to the ON position.

CAUTION: Adding more than 3 pounds (1.5 kg)

of warm food per cubic foot of freezer capacity can trigger the alarm.

To activate the alarm, set the switch to the

ON position.

To deactivate the alarm, set the switch to the

OFF position.

Located on back of lid.

5

Support Consumer Tips Troubleshooting Instructions

Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions

About the operation of your freezer.

6

Instructions Safety

For Complete Defrosting

1 Turn the temperature control to the OFF position and unplug the freezer.

2 Remove all food and place it in corrugated boxes, insulated bags, picnic coolers, etc. Use towels and newspapers for insulation as needed.

3 With the door/lid open, use pans of hot water to speed loosening of frost. Remove large pieces before they melt.

Chest models have a defrost water drain at the front.

NOTE: Water may drip from the back flange of the lid cover during defrosting. This is normal. Ice builds up in the lid insulation when the lid is open for adding or removing food, and melts during the defrosting operation.

4

5

6

7

Sponge excess water from the bottom of the freezer as it collects to prevent overflowing.

After defrosting, clean the inside of the freezer (see Care and Cleaning).

Replace the drain plug inside the cabinet and the cap on the defrost drain. Fold over and dry the gasket on the hinge side of the lid.

Plug in the freezer. Return the temperature control to its previous position and return food to the freezer.

Support Consumer Tips Troubleshooting Instructions Installation Instructions Operating

7

Care and cleaning of the freezer.

Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions

Cleaning Your Freezer

???Outside. Protect the paint finish. The finish on the outside of the freezer is a high quality, baked-on paint finish. With proper care, it will stay new-looking and rust-free for years. Apply a coat of appliance polish wax when the freezer is new and then at least twice a year. Appliance polish wax also works well to remove tape residue from freezer surfaces.

Keep the finish clean. Wipe with a clean cloth lightly dampened with appliance polish wax or mild liquid dishwashing detergent. Dry and polish with a clean, soft cloth. Do not wipe the freezer with a soiled dishwashing cloth or wet towel. Do not use scouring pads, powdered cleaners, bleach, or cleaners containing bleach.

CAUTION: Care should be taken in moving the freezer away from the wall. All types of floor coverings can be damaged, particularly cushioned coverings and those with embossed surfaces.

???Inside. Clean the inside of your freezer at least once a year. We recommend that the freezer be unplugged before cleaning. If this is not practical, wring excess moisture out of sponge or cloth when cleaning in the vicinity of switches, lights or controls.

Use warm water and baking soda solution???about a tablespoon of baking soda to a quart of water. Rinse thoroughly with water and wipe dry. Do not use cleaning powders or other abrasive cleaners.

An open box of baking soda in the freezer will absorb stale freezer odors. Change the box every three months.

8

Instructions Operating Instructions Safety

Preparing for Vacation

To maintain freezer in operation during vacations, be sure your house power is not turned off. For sure protection of freezer contents, you may want to ask a neighbor to check the power supply and freezer operation every 48 hours.

For extended vacations or absences, you may prefer to move your frozen foods to a storage locker temporarily. If your freezer is to be left empty, disconnect power cord plug from wall outlet. To prevent formation of odors, place open box of baking soda in freezer and leave freezer door/lid open.

When the freezer is not operating, it can be left in an unheated house or room without damage to cabinet or mechanism.

Support Consumer Tips Troubleshooting Instructions Installation

9

Safety Instructions

Preparing to install the freezer.

Read these instructions completely and carefully.

Freezer Location

Instructions

Your freezer should be conveniently located for day-to-day use in a dry, well-ventilated room.

Do not install the freezer where the temperature will go below 0?? F or above 110?? F, because it will not maintain proper temperatures.

Be sure to install your freezer on a floor strong enough to support it when it is fully loaded.

The freezer must be solidly positioned on the floor if it is to function at its best. Shims may be used to accomplish this wherever the floor is too uneven.

If the place selected for the freezer is damp or moist, place 2 X 4???s (51 mm X 102 mm) under its entire length to assure adequate support.

Consumer Support Troubleshooting Tips Installation Instructions Operating

Clearances

On all models, allow 3??? (76 mm) on top, back and sides for proper air circulation.

10

These things are normal and

do not indicate a need for service.

???A warm cabinet exterior as the refrigeration system transfers heat from the inside to the outside through the exterior cabinet walls.

???The sound of the high-efficiency compressor motor.

Before you call for service???

Troubleshooting Tips

Save time and money! Review the charts on the following pages first and you may not need to call for service.

11

Support Consumer Tips Troubleshooting Instructions Installation Instructions Operating Instructions Safety

Consumer Support Troubleshooting Tips Installation Instructions Operating Instructions Safety Instructions

Before you call for service???

NOTE: Do not return the freezer to the store where you purchased it. The freezer is eligible for in-home service. For warranty service, contact us at www.GEAppliances.com, or call 800-GE-CARES (U.S.), or 1-800-361-3400 (Canada).

12

GE Service Protection Plus???

GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus??????comprehensive protection on all your appliances???

No Matter What Brand!

Benefits Include:

???Backed by GE

???All brands covered

???Unlimited service calls

???All parts and labor costs included

???No out-of-pocket expenses

???No hidden deductibles

???One 800 number to call

We???ll Cover Any Appliance.

Anywhere. Anytime.*

You will be completely satisfied with our service protection or you may request your money back on the remaining value of your contract. No questions asked. It???s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more???any brand! Plus there???s no extra charge for emergency service and low monthly financing is available. Even icemaker coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800-626-2224 for more information.

*All brands covered, up to 20 years old, in the continental U.S.

???Cut here

Please place in envelope and mail to:

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

13

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Read your Owner???s Manual carefully. It will help you operate your new appliance properly.

Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at www.GEAppliances.com.

???Cut here

Consumer Product Ownership Registration

GE Appliances

GE Consumer Products

General Electric Company

Louisville, Kentucky

www.GEAppliances.com

*Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important communications from GE Appliances (GEA).

??? Check here if you do not want to receive communications from GEA???s carefully selected partners.

FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR

WARRANTY RIGHTS.

For information about GEA???s privacy and data usage policy, go to www.GEAppliances.com and click on ???Privacy Policy??? or call 800.626.2224.

14

Freezer Warranty.

Within 30 days after food spoilage occurs, you must provide satisfactory proof of the spoilage to a Factory Service Center, an authorized Customer Care?? servicer or the dealer from whom the freezer was purchased.

What GE Will Not Cover:

Instructions Installation Instructions Operating Instructions Safety

???Service trips to your home to teach you how to use the product.

???Improper installation, delivery or maintenance.

???Failure of the product if it is abused, misused, or used for other than the intended purpose or used commercially.

???Food spoilage caused by:

a)Power interruption from the utility.

b)Blown fuse, open circuit breaker or other power disconnection on the owner???s premises.

c)Freezer not operating because of abnormally low electric power voltage or inadequate house wiring.

???Damage caused after delivery.

???Replacement of house fuses or resetting of circuit breakers.

???Damage to the product caused by accident, fire, floods or acts of God.

???Incidental or consequential damage caused by possible defects with this appliance.

Tips Troubleshooting

This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA and Canada. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state???s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

Camco Inc., Suite 310, 1 Factory Lane, Moncton, N.B. E1C 9M3

15

Support Consumer

Consumer Support.

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner???s Manuals, order parts, catalogs, or even schedule service on-line. You can also ???Ask Our Team of Experts??????

your questions, and so much more...

Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours any day of the year! Or call 800-GE-CARES (800-432-2737) during normal business hours.

GE supports the Universal Design concept???products, services and environments that can be used by people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and impairments. For details of GE???s Universal Design applications, including kitchen design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800-TDD-GEAC (800-833-4322).

Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still in effect. You can purchase it on-line anytime, or call 800-626-2224 during normal business hours. GE Consumer Home Services will still be there after your warranty expires.

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at 800-626-2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.

If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations

GE Appliances, Appliance Park Louisville, KY 40225

Register your new appliance on-line???at your convenience! Timely product registration will allow for enhanced communication and prompt service under the terms of your warranty, should the need arise. You may also mail in the pre-printed registration card included in the packing material.
